Overview

Congratulations on the purchase of your
new Bosch appliance.

On the following pages of these operating
instructions you will find useful information
for safe use of this appliance.
We request that you read these operating
instructions carefully and observe all
instructions. This ensures you will be able
to enjoy this appliance for a long time, and
the results will confirm your choice of this
appliance.
Retain these operating instructions for
subsequent use or for the next owner.
You can find further information about our
products on our website.

Content

Intended use ............................................. 18
Safety instructions .................................... 19
Overview................................................... 20
Before using for the first time.................... 21
Control and display elements ................... 21
Overload protection .................................. 22
Speed setting............................................ 22
Reversing function .................................... 22
Base unit................................................... 23
Base attachment....................................... 23
Shredding attachment .............................. 24
Citrus press attachment............................ 25
Grain mill attachment................................ 25
Fruit press attachment .............................. 26
Care and daily cleaning ............................ 27
Recipes..................................................... 28
Tips ........................................................... 28
Disposal .................................................... 29
Guarantee................................................. 29
Spare parts and accessories .................... 30
Troubleshooting ........................................ 31

Overview

X

Fig.

A

1  Base unit

a

Drive for attachments

b

Button

ä

or

k

*

c

Button

ö

or

+

*

d

Operation indicator

e

Release button

f

Carrying handle

g

Storage compartment with cover

h

Mains cable

i

Cable storage compartment

2  Base attachment

a

Housing

b

Feed chute

c

Filling tray

d

Pusher

e

Worm gear with agitator paddle

f

Threaded ring

3  Meat mincer insert

a

Blade

b

Perforated disc, fine (2,7 mm)*

c

Perforated disc, medium (4 mm)

d

Perforated disc, coarse (8 mm)

4  Sausage filler insert

a

Bearing ring

b

Sausage filler nozzle

X

Fig.

C

5  Shredding attachment*

a

Housing

b

Feed chute

c

Cap

d

Filling tray

e

Pusher

f

Slicing insert

g

Shredding insert, coarse

h

Shredding insert, fine

i

Grating insert

6  Citrus press attachment*

a

Collecting tray

b

Filter insert

c

Pressing cone

d

Driving shaft with spring
