Sven АС PS-800 - Инструкция по эксплуатации - Страница 6

ENG

6

Party Speaker System

with Bluetooth and FM-radio

The system will enter the Player mode automatically when a carrier (USB flash or SD card) is con

-

nected to corresponding ports. Use button

o

 to switch between Play/Pause modes. You can control

tracks by using buttons

l

 (previous track) and

q

 (next track).The use in the wired mode (LINE IN).

•

Speaker system can be used as an external device for amplifying any audio source with a 3.5 mm

output mini-jack. Connect a cable mini USB, plug 3.5 mini-jack to the audio input AUX

f

. Turn

the speakers to the LINE IN mode — press the MODE button

k

 several times until “LINE” appears

on the display.

Connecting an additional speaker

For model PS-800 you can connect an additional speaker.

•

For TWS connection in Bluetooth mode:

–

Turn both speakers into Bluetooth mode (both speakers should be in search mode).

–

On another speaker press and hold button MENU

p

 on control panel or TWS button

f

on Remote control.

–

If two speakers are successfully connected between themselves, the master unit will display

“BLUE” constantly, the slave unit will display “SLAU”.

–

Connect the signal source via Bluetooth. Both speakers will appear in the search list as one

device.

•

For connection in other modes (FM radio/Player/LINE IN):

–

on any speaker, press and hold the MENU button

p

 on the control panel or the TWS button

f

 on the remote control.

–

If two speakers are successfully connected to each other, the operating mode will be displayed

on the master device, and “SLAU” will be displayed on the slave device.

Reset

To reset the settings, long press the RESET

n

 on remote control. Settings will reset.

TECHNICAL SPECIFICATIONS

Parameter, measurement unit

Value

Frequency response, Hz

40–22 000

Output power (RMS), W

100 (2 × 50)

Speaker diameter, mm

Ø 38 + Ø 145

Battery capacity, mA*h

4 400 (2 pcs)

Power supply, V

~230/50

⧈

, 9V/1.5A

Weight, g

5 200

Dimensions, mm

312 × 325 × 568

Notes. Technical specifications given in this table are supplemental information and cannot give

occasion to claims. Technical specifications and package contents are subject to change without

notice due to the improvement of SVEN production.

Technical support is on www.sven.fi.
