19

•  lance hose;

•  bag of accessories with:

-  the operating and maintenance manual;

-  the engine operating and maintenance manual;

-  the declaration of conformity;

-  the booklet giving the assistance centres;

-  the warranty certificate;

-  suction kit with: fitting, gasket and clamp;

-  nozzle cleaning needle;

If any problems arise please contact your dealer or an authorised assistance centre.

OPTIONAL ACCESSORIES

You can add the following range of accessories to the standard ones supplied with your high pressure

cleaner:

•  sandblasting lance: designed to smooth surfaces, removing rust, paint, encrustations, etc.;

•  drain cleaning kit: designed to unclog pipes and ducts;

•  different types of lances and nozzles;

•  rotating brush: designed for cleaning fragile surfaces;

•  rotating nozzle: designed for removing stubborn dirt;

•  foam lance: designed for a more efficient distribution of the detergent;

INSTALLATION - ASSEMBLING THE ACCESSORIES

AND FILLING THE ENGINE CRANKCASE WITH OIL

•  Unwind the high pressure hose (30) and screw the end without the quickfit coupling onto the spray

gun (19) thread and tighten well with two 22 mm fixed jaw spanners (not supplied).

Operation B

 in Fig. 4.

•  Connect the quickfit coupling (34) to the water outlet fitting (15), screw down and tighten the ring nut

by hand.

Operation C

 in Fig. 4.

•  Insert the water inlet filter (39) in the water inlet fitting (16).

Operation D

 in Fig. 4.

• Fill the engine crankcase with oil, following the instructions given in the relevant operating and

maintenance manual (this is not to be done on machines with Diesel engines as they are filled with

oil in the factory).

OPERATION – PRELIMINARY ACTIVITIES

• Do the preliminary activities described in the operating and maintenance manual of the engine

mounted on the high pressure cleaner. In particular remember to fill with fuel and check the level of

engine oil.

•  When the engine is off and the machine is completely cold, check the level of pump oil by way of the

level indicator (38). Also check the gearbox oil level by way of the level indicator (44) on those models

thus equipped.

  When topping up is needed please refer to the lubricant types given in the

“s

peCiFiCations

and

teChniCal

data

”

paragraph.

•  Check correct tyre inflation.

•  Check that the inlet water filter (39) and the detergent suction filter (40) are clean.

•  Take the high pressure cleaner to the place of work using the handle (4).

•  Unwind the high pressure hose completely (30).

•  Connect a gardening type quickfit coupling to the water inlet hose-end fitting (39).

Operation G

 in

Fig. 4.

•  Start the engine, referring to the relevant operating and maintenance manual.

•  Open the water supply tap (if connected to the drinking water mains it is mandatory to use a back-flow

preventer: to use this device refer to the relevant instruction manual), making sure there are no drips.

Alternatively, put a suction hose in a tank.

EN
