18

ENI MULTITECH THT corresponding oils:

Mobil Mobilfluid 424

Mobil Mobilfluid 426

Petronas Arbor MTF Special 10W-30

Shell Spirax S4 TXM

Total Dynatrans MPV

Elf Tractelf BF16

Castrol Agri Trans Plus 80W

Chevron Textran THD Premium

Q8 Roloil Multivariax 35 HP

WARNING

•

As far as engine lubricants are concerned, refer to the relative operating and maintenance manuals.

IDENTIFICATION OF COMPONENTS

Refer to figures 1 to 4.

1

  - Pump

2

  -  Petrol/gasoline engines

3

  - Frame

4

  - Handle

8

  -  Warning plate

9

  -  Accessory rack

11

  -  Water inlet hose-end fitting

12

  -  Water inlet hose clamp

13

  -  ID plate

14

  - Base

15

  -  Water outlet fitting

16

  -  Water inlet fitting

17

  -  Pressure regulating knob

18

  -  Pressure indicator

19

  -  Spray gun

20

  -  Thermal valve

21

  -  Single barrel lance hose

24

  -  Single barrel nozzle holder head

25

 - Detergent tank

26

  - Detergent tank cap with dosing device

27

  -  Oil plug with vent for pump

29

  -  Nozzle cleaning needle

30

  -  High pressure hose

31

  -  Detergent suction hose

32

  -  Spray gun lever safety stop

33

  -  Spray gun lever

34

  -  High pressure hose quickfit coupling

36

  -  Detergent suction fitting

37

  -  Detergent suction hose clamp

38

  -  Pump oil level indicator

39

  -  Water inlet filter

40

  -  Detergent suction filter

44

  -  Gearbox oil level indicator (2W PRO)

46

  -  Oil plug with vent for gearbox (2W PRO)

SAFETY DEVICES

•  Pressure unloader/regulation valve

  Valve, suitably calibrated by the Manufacturer, for regulating work pressure by means of a knob (17)

and that allows the pumped fluid to return to pump suction thus preventing the onset of dangerous

pressures when closing the spray gun or when trying to set a pressure that is above the maximum

permitted values.

•  Spray gun lever lock device.

  Safety stop (32) for locking the spray gun (19) lever (33) in the closed position so it cannot be started

accidentally (Fig. 3, position S).

•

thermostatic valve

: designed to prevent the pump gaskets from overheating during prolonged

operation in bypass.

STANDARD FITTING

Make sure the following are inside the pack of the product you have purchased:

•  high pressure cleaner;

•  high pressure delivery hose;

•  spray gun;
