The warranty terms published by the relevant sales
company are applicable in each country. We will repair
potential failures of your appliance within the warranty
period free of charge, provided that such failure is
caused by faulty material or defects in manufacturing. In
the event of a warranty claim please contact your dealer
or the nearest authorized Customer Service centre.
Please submit the proof of purchase.
Addresses can be found under:
www.kaercher.com/dealersearch
Only use original accessories and spare parts, they en-
sure the safe and trouble-free operation of the device.
For information about accessories and spare parts,
please visit www.kaercher.com.
We hereby declare that the machine described below
complies with the relevant basic safety and health re-
quirements of the EU Directives, both in its basic design
and construction as well as in the version put into circu-
lation by us. This declaration shall cease to be valid if
the machine is modified without our prior approval.
The undersigned act on behalf and under the power of
attorney of the company management.
Authorised Documentation Representative
S. Reiser
Alfred Kärcher GmbH Co. KG
Alfred-Kärcher-Str. 28 - 40
71364 Winnenden (Germany)
Phone: +49 7195 14-0
Fax: +49 7195 14-2212
Winnenden, 2016/08/01
Warranty
Technical specifications
Electrical connection
Nominal battery voltage
6 V
Rated power of appliance
45 W
Protection class
IP X4
Protective class
Charging time for empty battery
3 h
Rated charger voltage
100-240
1~50-60
V
Hz
Output voltage, charger
9.5 V
Output current, charger
600 mA
Operating time with full charge
15 min
Max. Suction height
0.5 m
Performance data
Working pressure
0.5 MPa
Volume, fresh water reservoir
4 l
Max. ambient temperature
40 °C
Ambient temperature (min.)
0 °C
Dimensions and weights
Length
235 mm
Width
277 mm
Height
202 mm
Weight, ready to operate with ac-
cessories
6.2 kg
Values determined as per EN 60335-2-79
Sound pressure level L
pA
Uncertainty K
pA
69
3
dB(A)
dB(A)
Sound power level L
WA
+ Uncertain-
ty K
WA
84 dB(A)
Subject to technical changes.
Accessories and Spare Parts
EU Declaration of Conformity
Product:
Mobile Outdoor Cleaner
Type:
1.680-xxx
Relevant EU Directives
2014/35/EU
2014/30/EU
2011/65/EU
2009/125/EC
2000/14/EC
Applied regulations
278/2009
Applied harmonized standards
EN 60335–1
EN 60335–2–54
EN 62233: 2008
EN 55014–1: 2006+A1: 2009+A2: 2011
EN 55014–2: 2015
EN 61558–1
EN 61558–2–16
EN 61000–3–2: 2014
EN 61000–3–3: 2013
EN 50581
EN 50563
Applied conformity evaluation method
2000/14/EC: Appendix V
Sound power level dB(A)
OC 3
Measured:
81
Guaranteed:
84
CEO
Head of Approbation
16
EN
