– 4

These operating instructions describe the maximum
equipment. Depending on the model, there are differ-
ences in the scopes of delivery (see packaging).

See fold-out page 4 for illustrations

1

Trigger gun

2

Water reservoir

3

Water reservoir cover

4

Carry handle for water reservoir

5

Valve opener

6

Fine filter

7

Storage compartment for small parts

8

Carrying handle of the appliance

9

Power switch

10 Charging box
11 Battery charge indicator
12 Charger
13 Flat jet nozzle

* Optional accessories

14 Conical jet nozzle - for gentle cleaning
15 Universal brush
16 Micro fibre cloth
17 Viscous cloth
18 Fur cleaning brush
19 Accessories box
20 Suction hose
21 Suction hose connection
22 Water filter
23 Locking flap

The scope of delivery of the device is illustrated on the
packaging. Check the content for completeness upon
unpacking.
In the event of missing accessories or any transport
damage, please contact your dealer.

Special accessories expand the possibilities of using
your appliance. Please contact your KÄRCHER dealer
for further information.



Park the appliance on an even surface.

Illustration

Note

: During the charging process, the charge/operat-

ing display blinks. Once the battery is fully charged, it
will be permanently illuminated.
The charging process takes approx. 3 hours.

ATTENTION

Contamination in the water can damage the pump and
the accessories.



Only fill or suction clear water into the tank.

ATTENTION

Do not fill with detergents, pesticides or other additives!
Do not immerse the device into water.
Remove the water reservoir for filling.

Illustrations

 -

Illustrations

 -



Pull the water reservoir straight up.



Remove the valve opener and fine filter using the
suction hose connection or a suitable pair of pliers.



Insert the suction hose connection into the device
in place of the fine filter and fix by turning it 90°.



Hang the suction hose with the integrated filter into
the water source (e.g. rainwater drum).

ATTENTION

Store the valve opener and the fine filter safely in the
storage compartment and insert them again prior to use
with the water reservoir.

Note:

Ensure that the pin of the valve opener points up-

wards.

ATTENTION

Dry running of more than 2 minutes leads to damage to
the pump. If the device does not build up pressure within
2 minutes, switch the device off and proceed in accord-
ance with the instructions in the chapter "Troubleshoot-
ing".

Illustration
The operating time with the battery fully charged is
about 15 minutes. Approx. 2 minutes before the operat-
ing time ends, the charge level indicator will start to
flash.

몇

CAUTION

Do not direct the spray jet at eyes or ears.

For gentle cleaning of fur and paws or particularly sen-
sitive components.
Illustration



Install the conical jet nozzle.

Description of the Appliance

Blink codes

Battery is being
charged.

Battery is fully charged.

Low battery voltage warn-
ing (approx. 2 minutes op-
erating time remaining).
Battery discharged - de-
vice switches itself off and
cannot be switched back
on.
Malfunction: Motor circuit
breaker has tripped (See
"Troubleshooting").

Scope of delivery

Special accessories

Start up

Charge the battery

Water supply

Water supply from integrated water reservoir

Drawing in water from open reservoirs

Operation

Operation with conical jet nozzle

14

EN
