– 7
Only use original accessories and spare parts, they en-
sure the safe and trouble-free operation of the device.
For information about accessories and spare parts,
please visit www.kaercher.com.
The warranty terms published by the relevant sales
company are applicable in each country. We will repair
potential failures of your appliance within the warranty
period free of charge, provided that such failure is
caused by faulty material or defects in manufacturing. In
the event of a warranty claim please contact your dealer
or the nearest authorized Customer Service centre.
Please submit the proof of purchase.
Addresses can be found under:
www.kaercher.com/dealersearch
We hereby declare that the machine described below
complies with the relevant basic safety and health re-
quirements of the EU Directives, both in its basic design
and construction as well as in the version put into circu-
lation by us. This declaration shall cease to be valid if
the machine is modified without our prior approval.
The undersigned act on behalf and under the power of
attorney of the company management.
Authorised Documentation Representative
S. Reiser
Alfred Kärcher GmbH Co. KG
Alfred-Kärcher-Str. 28 - 40
71364 Winnenden (Germany)
Phone: +49 7195 14-0
Fax: +49 7195 14-2212
Accessories and Spare Parts
Technical specifications
Electrical connection
Voltage
220-240
1~50-60
V
Hz
Power consumption
6 A
Protection class
IP X5
Protective class
II
Mains fuse (slow-blow)
10 A
Water connection
Max. feed pressure
1,2 MPa
Max. feed temperature
40 °C
Min. feed volume
8 l/min
Performance data
Working pressure
8 MPa
Max. permissible pressure
12 MPa
Water flow rate
5,5 l/min
Max. flow rate
6,3 l/min
Detergent flow rate
0,3 I/min
Recoil force of trigger gun
12 N
Dimensions and weights
Length
307 mm
Width
272 mm
Height
600 mm
Weight, ready to operate with acces-
sories
5,1 kg
Values determined as per EN 60335-2-79
Hand-arm vibration value
Uncertainty K
<2,5
0,6
m/s
2
m/s
2
Sound pressure level L
pA
Uncertainty K
pA
72
3
dB(A)
dB(A)
Sound power level L
WA
+ Uncertainty
K
WA
88 dB(A)
Subject to technical changes.
Warranty
EU Declaration of Conformity
Product:
High pressure cleaner
Type:
1.602-xxx
Relevant EU Directives
2000/14/EC
2014/30/EU
2006/42/EC (+2009/127/EC)
2011/65/EU
Applied harmonized standards
EN 50581
EN 55014–1: 2006+A1: 2009+A2: 2011
EN 55014–2: 2015
EN 60335–1
EN 60335–2–79
EN 61000–3–2: 2014
EN 61000–3–3: 2013
EN 62233: 2008
Applied conformity evaluation method
2000/14/EC: Appendix V
Sound power level dB(A)
Measured:
85
Guaranteed:
88
Winnenden, 2016/08/01
CEO
Head of Approbation
11
EN
