Subject to technical modifications!

We hereby declare that the machine described
below complies with the relevant basic safety
and health requirements of the EU Directives,
both in its basic design and construction as well
as in the version put into circulation by us. This
declaration shall cease to be valid if the machine
is modified without our prior approval.

The undersigned act on behalf and under the
power of attorney of the company management.

Alfred Kärcher GmbH Co. KG
Alfred-Kärcher-Str. 28 - 40
D - 71364 Winnenden
Phone: +49 7195 14-0
Fax: +49 7195 14-2212

Specifications

Connected load

1,9 kW

Working pressure

12 MPa

Max. permissible pressure

14 MPa

Water flow rate

6,7 I/min

Power connection

Voltage *EUR
1~50 Hz
Voltage *AUS
1~50 Hz

230

240

V

V

Mains fuse (slow-blow)

10 A

Protective class

I

Protection class

IP X5

Water connection

Max. feed temperature

40 °C

Min. feed volume

10 I/min

Max. feed pressure

1,2 MPa

Suction height (max.)

0,5 m

Detergent flow rate

0,3 I/min

Recoil force of trigger gun

15 N

Hand-arm vibration
(ISO 5349)

1,29 m/s²

Sound pressure level
L

pA

 (EN60704-1)

73 dB(A)

Sound power level
L

WA

 (2000/14/EG)

88 dB(A)

Dimensions

Length

372 mm

Width

355 mm

Height

902 mm

Weight

15 kg

CE declaration

Product:

High-pressure cleaner

Type:

1.636-xxx

Relevant EU Directives

98/37/EC (to 28.12.2009)
2006/42/EC (from 29.12.2009)
2004/108/EC
2000/14/EC

Applied harmonized standards

EN 60335–1
EN 60335–2–79
EN 55014–1: 2006
EN 55014–2: 1997 + A1: 2001
EN 61000–3–2: 2006
EN 61000–3–3: 2008
EN 50366: 2003 + A1: 2006

Applied conformity evaluation method

Appendix V

Sound power level dB(A)

Measured:

86

Guaranteed:

88

CEO

Head of Approbation
