– 10

Subject to technical modifications!

We hereby declare that the machine de-
scribed below complies with the relevant
basic safety and health requirements of the
EU Directives, both in its basic design and
construction as well as in the version put
into circulation by us. This declaration shall
cease to be valid if the machine is modified
without our prior approval.

The undersigned act on behalf and under
the power of attorney of the company man-
agement.

Authorised Documentation Representative
S. Reiser

Alfred Kärcher GmbH Co. KG
Alfred-Kärcher-Str. 28 - 40
71364 Winnenden (Germany)
Phone: +49 7195 14-0
Fax: +49 7195 14-2212

Winnenden, 2011/10/01

Technical specifications

Electrical connection

Voltage

230

1~50

V
Hz

Connected load

2,0 kW

Protection class

IP X5

Protective class

I

Mains fuse (slow-blow)

10 A

Water connection

Max. feed pressure

1,2 MPa

Max. feed temperature

40 °C

Min. feed volume

10 I/min

Performance data

Working pressure

12 MPa

Max. permissible pressure

14 MPa

Water flow rate

7,5 I/min

Detergent flow rate

0,4 I/min

Recoil force of trigger gun

21 N

Dimensions and weights

Length

508 mm

Width

255 mm

Height

284 mm

Weight, ready to operate with
accessories

14,8 kg

Values determined as per EN 60335-2-79

Hand-arm vibration value
Uncertainty K

<2,5

0,3

m/s

2

m/s

2

Sound pressure level L

pA

Uncertainty K

pA

82

2

dB(A)
dB(A)

Sound power level L

WA

 +

Uncertainty K

WA

97 dB(A)

EC Declaration of Conformity

Product:

High-pressure cleaner

Type:

1.069-xxx

Relevant EU Directives

2006/42/EC (+2009/127/EC)
2004/108/EC
2000/14/EC

Applied harmonized standards

EN 55014–1: 2006 + A1: 2009
EN 55014–2: 1997 + A2: 2008
EN 60335–1
EN 60335–2–79
EN 61000–3–2: 2006 + A2: 2009
EN 61000–3–3: 2008
EN 62233: 2008

Applied conformity evaluation method

2000/14/EC: Appendix V

Sound power level dB(A)

Measured:

95

Guaranteed:

97

CEO

Head of Approbation
