These operating instructions describe the
maximum equipment. Depending on the
model, there are differences in the scopes
of delivery (see packaging).
Illustrations on fold-out page!
1 Coupling element for water
connection
2 Quick coupling for high pressure hose
3 Storage for trigger gun
4 Water connection with integrated sieve
5 Appliance switch "0/OFF“/ „I/ON“
6 Dosage regulator for detergent
7 Storage for trigger gun
8 Transport handle
9 Storage of Plug 'n' Clean detergent bot-
tle with detergent connection
10 Plug 'n' Clean detergent bottle with
locking lid
11 Storage for high pressure hose
12 Storage hook for mains connection cable
13 Storage for spray lance
14 Mains cable with mains plug
15 Transport wheel with wheel cap
16 Trigger gun
17 Lock trigger gun
18 Key to detach the high pressure hose
from the trigger gun
19 High pressure hose
20 Spray lance with pressure regulation
(Vario Power)
Carrying out the most common cleaning
tasks. The work pressure can be stage-
lessly regulated between "Min" and
"Max". You can add detergent when
"Mix" is selected.
In order to adjust the working pressure,
release the lever of the hand spray gun
and turn the spray lance to the desired
position.
21 Spray lance with Dirtblaster
For strong contaminations
———————————————–
Optional accessories
22 Washing brush
Suitable for use with detergents.
23 Rotary washing brush
Suitable for use with detergents.
Especially suitable for cleaning cars.
24 Foam nozzle with detergent container
With powerful foam for effortless cleaning.
———————————————–
Not included in the delivery
25 Water supply hose
Use a fabric reinforced water hose with
a commercially available coupling. Min-
imum diameter 13 mm (1/2 inch); mini-
mum length 7.5 m.
Illustrations on fold-out page!
Mount loose parts delivered with
appliance prior to start-up.
Illustration
Push the wheels into the intake and se-
cure them with the plugs. Align the plug
properly.
Illustration
Place the bottom holder into the recess-
es and push forward until it audibly
locks in.
Insert the top holder and push down all
the way.
You will need the 2 included screws as well
as a Phillips screwdriver PH 2.
Illustration
Slide the transport handle into the guide
and secure it with 2 screws.
You will need the 2 included screws as well
as a Phillips screwdriver PH 2.
Illustration
Insert both detergent hoses onto the
hose fittings.
Install the dosage regulator and con-
nect using 2 screws.
Note
: During installation you must
make sure that the tongues of the dos-
age regulator match up with the intend-
ed recesses in the casing.
Description of the Appliance
Before Startup
Attaching the Accessories
Install wheels
Install the storage for trigger gun
Install the transport handle
Install the dosage regulator for detergent
