– 6

These operating instructions describe the
maximum equipment. Depending on the
model, there are differences in the scopes
of delivery (see packaging).

Illustrations on Page 2

1 High pressure connection
2 Appliance switch "0/OFF“/ „I/ON“
3 Storage hook for high pressure hose

and mains connection cable

4 Carrying handle
5 Storage for spray lance
6 Storage for trigger gun
7 Water connection with integrated sieve
8 Detergent suction hose (with sieve)
9 Coupling element for water connection
10 Mains cable with mains plug
11 Trigger gun
12 Lock trigger gun
13 Clamp for high pressure hose
14 High pressure hose

———————————————––––

Optional accessories

15 Spray lance with Dirtblaster

For strong contaminations

16 Spray lance with high pressure nozzle

For normal cleaning tasks.
———————————————––––

Not included in the delivery

17 Water supply hose

Use a fabric reinforced water hose with
a commercially available coupling. Min-
imum diameter 13 mm (1/2 inch); mini-
mum length 7.5 m.

Mount loose parts delivered with appliance
prior to start-up.

Illustrations on Page 2

Illustration



Attach the transport handle.

Illustration



Pull out the clamp for the high-pressure
hose from the hand spray gun (e.g. a
Philips screwdriver).

Illustration



Connect high pressure hose to trigger
gun.



Push the clamp in until it locks. Check
the secure connection by pulling on the
high-pressure hose.

Illustration



Screw the coupling element to the wa-
ter connection on the appliance.

For connection values, see type plate/tech-
nical data.
Observe regulations of water supplier.

몇

Warning

According to applicable regulations, the ap-
pliance must never be used on the drinking
water net without a system separator. A
suitable system separator by KÄRCHER or
alternatively a system separator according
to EN 12729 type BA must be used.
Water that has flown through a system sep-
arator is no longer classified as drinking
water.

Caution

Always connect the system separator to
the water supply, never directly to the appli-
ance!

Caution

Impurities in the water can damage the
high-pressure pump and the accessories.
For protection, the use of the KÄRCHER
water filter (optional accessory, order no.
4.730-059) is recommended.

Caution

Dry running of more than 2 minutes leads to
damage of the high-pressure pump. If the
appliance does not build up pressure within
2 minutes, switch the appliance off and pro-
ceed in accordance with the instructions in
Chapter "Troubleshooting".

Illustration



Connect the high pressure hose to the
high pressure connection of the appli-
ance.

Description of the Appliance

Before Startup

Attaching the Accessories

Water supply

Start up

14

EN
