– 6

Mount loose parts delivered with appliance prior
to start-up.

Illustrations on Page 2

Illustration

Î

Insert the transport handle and screw in.

Illustration

Î

Insert the transport wheels and lock them.

Illustration

Î

Pull out the clamp for the high-pressure hose
from the trigger gun (e.g. a small screwdriv-
er).

Illustration

Î

Connect high pressure hose to trigger gun.

Î

Push the clamp in until it locks. Check the se-
cure connection by pulling on the high-pres-
sure hose.

According to the applicable regula-
tions, the appliance must never be
used on the drinking water supply with-
out a system separator. Use a suitable
system separator manufactured by KÄRCHER;
or, as an alternative, a system separator as per
EN 12729 Type BA. Water flowing through a sys-
tem separator is considered non-drinkable.

Note:

 Impurities in the water can damage the

high-pressure pump and accessories. For pro-
tection, the use of the KÄRCHER water filter (op-
tional accessory, order no. 4.730-059) is
recommended.

Observe regulations of water supplier.
For connection values, see type plate/technical
data.

Î

Use a fibre-reinforced water hose (not in-
cluded) with a standard coupling. (Minimum
diameter 1/2 inch (13 mm), minimum length
7.5 m).

Î

Screw the coupling element (supplied) to the
water connection on the appliance.

Î

Push the water supply hose onto the cou-
pling unit, then connect it to the water supply.

Caution

Dry runs lasting longer than two minutes lead to
damages to the high pressure pump. If the appli-
ance does not build up pressure within two min-
utes, switch it off and proceed as instructed in
the Chapter "Troubleshooting".

Î

Connect the high pressure hose to the high
pressure connection of the appliance.

Î

Push the spray lance into the trigger gun and
fasten it by turning it through 90°.

Î

Completely open the water tap.

Î

Insert the mains plug into the socket.

Î

Turn on the appliance “I/ON”.

몇

Danger

The trigger gun is subjected to a recoil force
when the water jet is discharged. Make sure that
you have a firm footing and are also holding the
trigger gun and spray lance firmly.

Î

Unlock the lever on the trigger gun.

Î

Pull on the lever of the trigger gun; the device
will switch on.

Note:

 Release the lever of the trigger gun; the

device will switch off again. High pressure re-
mains in the system.

For normal cleaning tasks.
Not suitable for use with detergents.

For particularly dirty items or areas.
Not suitable for use with detergents.

Please use exclusively KÄRCHER detergents
and care products to carry out the respective
cleaning task, as these were specifically devel-
opped for your appliance. The use of other deter-
gents and care products may lead to premature
wear and can invalidate your warranty claims.
Please obtain information at your local dealer or
request information directly from KÄRCHER.

Î

Pull detergent suction hose as far as is re-
quired out of the housing.

Î

Suspend end of detergent suction hose in a
container filled with detergent.

Î

Detach spray lance from the trigger gun.
Work only with the trigger gun.

Note:

 This will mix the detergent with the wa-

ter stream.

Î

Spray the detergent sparingly on the dry sur-
face and allow it to react, but not to dry.

Î

Spray off loosened dirt with the high-pres-
sure jet.

Before Startup

Water supply

Water supply from mains

Start up

Operation

Spray lance with high pressure nozzle

Spray lance with Dirtblaster

Working with detergent

Recommended cleaning method

13

EN
