– 2
Figure 1
1 Cover
2 Support for spray lance
(both sides)
3 System care Advance RM 110/RM 111
4 Steering roller with fixed position brake
5 Mounting location for transport
(both sides)
6 High pressure hose
7 Hand spraygun
8 Spray lance
9 High-pressure nozzle (stainless steel)
10 Power supply
11 Safety latch of the hand spray gun
12 Pressure/ quantity regulation at the
hand spray gun
13 Connection for water supply with filter
14 High pressure connection
15 Step depression
16 Pouring vent for detergent 2
17 Pouring vent for detergent 1
18 Folding compartment
19 Handle
20 Operating field
21 Closing flap for storage compartment
22 Storage compartment for accessories
23 Nameplate
24 Cover lock
25 Oil tank
26 Pressure/quantity regulation of the
pump unit
27 Oil drain screw
28 Backflow valve of the detergent infeed
29 Detergent suction hose 1 with filter
30 Detergent suction hose 2 with filter
31 System care service switch
32 Safety block with sieve
33 Boiler
34 Fine filter (water)
35 Boiler drain screw
Figure 2
A Power switch
B Temperature controller
C Dosage valve for detergent
D Manometer
1 Indicator lamp pump
2 ”Low water” indicator lamp
3 “Ready for use” indicator lamp
4 Indicator lamp - heating
5 Engine indicator lamp
6 Indicator lamp boiler fault
7 Indicator lamp service
8 Indicator lamp system care
High-pressure jets can be dan-
gerous if improperly used. The
jet may not be directed at per-
sons, animals, live electrical equipment or
at the appliance itself.
Cleaning of: Machines, Vehicles, Struc-
tures, Tools, Facades, Terraces, Garden-
ing tools, etc.
Danger
Risk of injury! Follow the respective safety
regulations when operating at gas stations
or other dangerous areas.
Overview
Device elements
Operating field
Symbols on the machine
Risk of electric shock!
Only electricians or authorised
technicians are permitted to
work on parts of the plant.
Risk of burns on account of hot
surfaces!
Proper use
Please do not let mineral oil contaminated
waste water reach soil, water or the sew-
age system. Perform engine cleaning and
bottom cleaning therefore only on speci-
fied places with an oil trap.
19
EN
