– 3

Î

Mount the nozzle on the spray pipe (mark-
ings on the adjustment ring at the top).

Î

Install spray pipe on the hand-spray gun
with pressure and volume regulation.

Note (for 1.524-207 only)

When space is limited, the enclosed adapt-
er with nozzle can be mounted directly to
the hand spray gun.

Î

Fasten the high pressure hose to the
high pressure connection.

Î

Insert the crank in the hose drum shaft
and lock it in.

Î

Before rolling up, stretch out the high
pressure hose.

Î

Wind the high pressure hose in uniform
layers on the hose drum by rotating the
crank.  Select the rotation direction in
such a way that the high pressure hose
does not get bent.

몇

Danger

Danger of injury by electric shock.
The appliance may only be connected to al-
ternating current.
The appliance may only be connected to an

electrical supply which has been installed in

accordance with IEC 60364.

The voltage indicated on the type plate

must correspond to the voltage of the elec-

trical source.

The minimum fuse rating required at the

socket outlet is (see technical specifications).

The highest allowed net impedance at the

electrical connection point (refer to techni-

cal data) is not to be exceeded. In case of

confusion regarding the power impedance

present on your connection, please contact

your utilities provider.

The appliance should always be connected

to the electrical mains using a plug. It is for-

bidden to permanently connect the appli-

ance to the power supply. The plug is only

for mains separation.

Check the power cord with mains plug for
damage before every use. If the power cord
is damaged, please arrange immediately
for the exchange by an authorized custom-
er service or a skilled electrician.
The plug and coupling of the extension ca-
ble used must be watertight.
Use the extension cord that has an ade-
quate cross-section (see "Technical Data")
and unwind it fully from the cable drum.
Unsuitable extension cables can be haz-
ardous. Only use extension cables out-
doors which have been approved for this
purpose and labelled with a sufficient cable
cross section:

For connection values, see type plate/tech-
nical data.

몇

Warning

Observe regulations of water supplier.
According to the applicable regula-
tions, the appliance must never be
used on the drinking water supply
without a system separator. Use a
suitable system separator manufactured by
KÄRCHER; or, as an alternative, a system
separator as per EN 12729 Type BA. Water
flowing through a system separator is con-
sidered non-drinkable.

Caution

Always connect the system separator to
the water supply, never directly to the appli-
ance!

For connection values refer to technical
specifications

Î

Connect the supply hose (minimum
length 7.5 m, minimum diameter 1“) to
the water connection point of the appli-
ance (such as the tap).

Note

The supply hose is not included.

Î

Open the water supply.

Attaching the Accessories

In devices without hose drum:

In devices without hose drum:

Start up

Electrical connection

Water connection

Connection to the water supply

20

EN
