– 3

Î

Mount the nozzle on the spray pipe (mark-
ings on the adjustment ring at the top).

Î

Connect ray tube to hand spray gun

Note

Only with HD 7/10 CXF:
When space is limited, the enclosed adapt-
er with nozzle can be mounted directly to
the hand spray gun.

Î

Loosen the clamps of the pushing handle.

Î

Adjust the handle to the desired height.

Î

Tighten the clamps of the pushing handle.

Î

Fasten the high pressure hose to the
high pressure connection.

Î

Insert the crank in the hose drum shaft
and lock it in.

Î

Before rolling up, stretch out the high
pressure hose.

Î

Wind the high pressure hose in uniform
layers on the hose drum by rotating the
crank.  Select the rotation direction in
such a way that the high pressure hose
does not get bent.



Danger

Danger of injury by electric shock.
The appliance may only be connected to al-
ternating current.
The appliance may only be connected to an
electrical supply which has been installed in
accordance with IEC 60364.
The voltage indicated on the type plate

must correspond to the voltage of the elec-

trical source.

The minimum fuse rating required at the

socket outlet is (see technical specifica-

tions).

The highest allowed net impedance at the
electrical connection point (refer to techni-
cal data) is not to be exceeded. In case of
confusion regarding the power impedance

present on your connection, please contact
your utilities provider.
The appliance should always be connected to
the electrical mains using a plug. It is forbidden
to permanently connect the appliance to the
power supply. The plug is only for mains sepa-
ration.
Check the power cord with mains plug for dam-

age before every use. If the power cord is dam-

aged, please arrange immediately for the

exchange by an authorized customer service or

a skilled electrician.

The plug and coupling of the extension cable

used must be watertight.

Use the extension cord that has an adequate

cross-section (see "Technical Data") and un-

wind it fully from the cable drum.

Unsuitable extension cables can be hazardous.

Only use extension cables outdoors which

have been approved for this purpose and la-

belled with a sufficient cable cross section:

For connection values, see type plate/tech-
nical data.

몇

Warning

Observe regulations of water supplier.
According to the applicable regula-
tions, the appliance must never be
used on the drinking water supply
without a system separator. Use a
suitable system separator manufactured by
KÄRCHER; or, as an alternative, a system
separator as per EN 12729 Type BA. Water
flowing through a system separator is con-
sidered non-drinkable.

Caution

Always connect the system separator to
the water supply, never directly to the appli-
ance!

For connection values refer to technical
specifications

Î

Connect the supply hose(minimu length 7.5
m, minimum diameter 1/2“) to the water
connection point of the machine and at the
water supply point (for e.g. a tap).

Attaching the Accessories

In devices without hose drum:

In devices without hose drum:

Start up

Electrical connection

Water connection

Connection to the water supply
