– 5



The oil level must be at the centre of the
oil level display.



Open the device hood.



Unscrew the screw plug.



Screw in oil filling screw.



Close cover.



Adjust the push handle on the appli-
ance.



Fasten the push handle with truss-head
screws, washers and nuts.



Connect spray lance to trigger gun.



Install nozzle with nozzle screw at the
spray lance.



Screw the high-pressure hose on to the
hand spray gun.



Fasten the high pressure hose to the
high pressure connection.



DANGER

Danger of injury by electric shock.
The appliance may only be connected to al-
ternating current.
The highest allowed net impedance at the
electrical connection point (refer to techni-
cal data) is not to be exceeded. In case of
confusion regarding the power impedance
present on your connection, please contact
your utilities provider.
It is imperative to connect the appliance to
the electric mains by means of a plug. It is
forbidden to permanently connect the appli-
ance to the power supply. The plug serves
for the disconnection from the mains.
Use the extension cord that has an ade-
quate cross-section (see "Technical Data")
and unwind it fully from the cable drum.

For connection values, see type plate/tech-
nical data.

몇

WARNING

Observe regulations of water supplier.
 According to applicable regula-
tions, the appliance must never be
used on the drinking water net
without a system separator. A suit-
able system separator by KÄRCHER or al-
ternatively a system separator according to
EN 12729 type BA must be used.
Water that was flowing through a system
separator is considered non-drinkable.

몇

CAUTION

Always connect the system separator to
the water supply, never directly to the appli-
ance!

For connection values refer to technical
specifications.



Connect the supply hose (minimum
length 7.5 m, minimum diameter 3/4“) to
the water connection point of the ma-
chine and at the water supply point (for
e.g. a tap).

Note:

The supply hose is not included.



Open the water supply.



Screw the suction hose onto the water
connection.

Note:

If a suction hose with a check valve or filter
is used, the hose must be filled with water.



Deaerate the appliance:
Unscrew the nozzle.
Switch on the appliance and let it run
until the water exiting is bubble-free.
At the end let the appliance run for ap-
prox. 10 seconds - then switch off. Re-
peat the procedure for a couple of
times.



Switch off the appliance and fit the noz-
zle again.

Check oil level

Activate deaeration of oil container

Installing the pushing handle

Attaching the Accessories

Start up

Electrical connection

Water connection

Connection to the water supply

Drawing in water from open reservoirs

18

EN
