– 2

Use this high pressure cleaner exclusively for

–

Cleaning using low pressure jet and de-

tergent (for e.g. for cleaning machines,

cars, buildings, tools),

–

For cleaning using high pressure jet

without detergent (for e.g. for cleaning

facades, terraces, garden appliances).

For stubborn dirt, we recommend the use of

the dirt blaster as a special accessory.

If the lever on the trigger gun is released the

pressure switch turns off the pump, the high-

pressure jet is stopped. If the lever is pulled the

pump is turned on again.

The overflow valve prevents the permissible

working pressure from being exceeded.

The overflow valve and pressure switch are set

and sealed at the factory.  Setting only by cus-

tomer service.

Setting only by customer service.

The motor protection switch switches off the de-

vice if the power consumption is high.

Safety devices serve to protect the user and

must not be rendered inoperational or their

functions bypassed.

Notes about the ingredients (REACH)

You will find current information about the
ingredients at:

http://www.karcher.de/de/unternehmen/
umweltschutz/REACH.htm

–

Check the contents of the pack before
unpacking.

–

In case of transport damage inform ven-
dor immediately



Read the oil level display when the de-
vice is not running. The oil level must be
above the two pointers.



Unscrew the fastening screws of the
device hood; remove the device hood.



Cut off tip of oil container cover



Fasten the device hood.



Install nozzle with nozzle screw at the
spray pipe.



Connect ray tube to hand spray gun



Tighten the screw connection of the
spray lance fingertight.



Insert the crank in the hose drum shaft
and lock it in.



Lock in the cable hook in the side-hole
on the handle.



Tighten the high-pressure connection
as required.



Lever out the safety clip of the handspray
gun using a screw-driver (Picture A).



Place the hand-spray gun upside down
and insert the end of the high pressure
hose till the end. Ensure that the lose
disc falls right below on the hose end
(Picture B).

Proper use

Safety Devices

Environmental protection

The packaging material can be
recycled. Please do not place
the packaging into the ordinary
refuse for disposal, but arrange
for the proper recycling.
Old appliances contain valuable
materials that can be recycled.
Please arrange for the proper
recycling of old appliances. Bat-
teries, oil, and similar substanc-
es must not enter the
environment. Please dispose of
your old appliances using appro-
priate collection systems.

Before Startup

Unpacking

Check oil level

Activate deaeration of oil container

Attaching the Accessories

In devices without hose drum:

In devices without hose drum:

For hand-spray guns with threaded con-
nection:

For hand-spray guns without threaded
connection:
