– 2

Use this high pressure cleaner exclusively for

–

Cleaning using low pressure jet and de-

tergent (for e.g. for cleaning machines,

cars, buildings, tools),

–

For cleaning using high pressure jet

without detergent (for e.g. for cleaning

facades, terraces, garden appliances).

For stubborn dirt, we recommend the use of

the dirt blaster as a special accessory.

Safety devices serve for the protection of the
user and must not be put out of operation or by-
passed with respect to their function.

The overflow valve prevents the permissi-
ble working pressure from being exceeded.

–

If the lever on the trigger gun is released

the pressure switch turns off the pump,

the high-pressure jet is stopped. If the

lever is pulled the pump is turned on

again.

–

The overflow valve and pressure switch

are set and sealed at the factory.  Set-

ting only by customer service.

The motor protection switch switches off
the device if the power consumption is high.

Notes about the ingredients (REACH)

You will find current information about the
ingredients at:

http://www.karcher.de/de/unternehmen/
umweltschutz/REACH.htm

–

Check the contents of the pack before
unpacking.

–

In case of transport damage inform ven-
dor immediately

Î

Read the oil level display when the de-
vice is not running. The oil level must be
above the two pointers.

Î

Unscrew the fastening screws of the
device hood; remove the device hood.

Î

Cut off tip of oil container cover

Î

Fasten the device hood.

Î

Install nozzle with nozzle screw at the
spray pipe.

Î

Connect ray tube to hand spray gun

Î

Insert the crank in the hose drum shaft
and lock it in.

Î

Lock in the cable hook in the side-hole
on the handle.

Î

Tighten the high-pressure connection
as required.

Î

Lever out the safety clip of the handspray
gun using a screw-driver (Picture A).

Î

Place the hand-spray gun upside down
and insert the end of the high pressure
hose till the end. Ensure that the lose
disc falls right below on the hose end
(Picture B).

Proper use

Safety Devices

Overflow valve

Pressure switch

Motor protection switch

Environmental protection

The packaging material can be

recycled. Please do not place

the packaging into the ordinary

refuse for disposal, but arrange

for the proper recycling.
Old appliances contain valuable

materials that can be recycled.

Please arrange for the proper re-

cycling of old appliances. Batter-

ies, oil, and similar substances

must not enter the environment.

Please dispose of your old appli-

ances using appropriate collec-

tion systems.

Before Startup

Unpacking

Check oil level

Activate deaeration of oil container

Attaching the Accessories

In devices without hose drum:

In devices without hose drum:

For hand-spray guns with threaded connection:

For hand-spray guns without threaded
connection:
