27

Example2: Set Brightness as 176 for TV-02 and this command is NOT valid Send (Hex Format)

Name

Length

ID

Command

Type

Command Value1

Value2

Value3

CR

Hex

0x38

0x30

0x32

0x73

0x24

0x31

0x37

0x36

0x0D

Reply (Hex Format)

Name

Length

ID

Command

Type

CR

Hex

0x34

0x30

0x32

0x2D

0x0D

Set function table:

Set Function Length

ID

Command

Type

Command

Value Range

Comments

Code (ASCII)

Code (Hex)

(Three ASCII bytes)

Power on/off

(standby)

8

s

!

21

000: STBY

001: ON

Controlled power

status: ON or Standby

Input Select

8

s

“

22

000 : TV

001 : AV

002 : S-Video

003 : YPbPr

004 : HDMI

014 : HDMI2

024 : HDMI3

005 : DVI

006 : VGA1(PC)

016 : VGA2

007 : OPS

008 : Internal Mem

009 : DP

1. No need for USB

2.  For the case of two

more same sources,

the 2nd digital is

used to indicate the

extension.

Contrast

8

s

#

23

000 ~ 100

Brightness

8

s

$

24

000 ~ 100

Sharpness

8

s

%

25

000 ~ 100

Color

8

s

&

26

000 ~ 100

Tint

8

s

‘

27

000 ~ 100

Color Mode

8

s

)

29

000 : Normal

001 : Warm

002 : Cold

003 : Personal

Bass

8

s

.

2E

000 ~ 100

Sets Bass value

Treble

8

s

/

2F

000 ~ 100

Sets Treble value

Balance

8

s

0

30

000 ~ 100

Sets Balance position

Picture Size

8

s

1

31

000 : FULL

001 : NORMAL

002 : CUSTOM

003 : DYNAMIC

004 : REAL

OSD Language

8

s

2

32

000 : English

001 : French

002 : Spanish

Power Lock

8

s

4

34

000 : Unlock

001 : Lock

Volume

8

s

5

35

000 ~ 100

900 : Volume down (-1)

901 : Volume up (+1)
