 ENGLISH

Steam collects on the door
and hot air comes out of the
ventilation openings.

During the cooking process, steam is released from the food.
Most of the steam is released through the ventilation openings,
but some can collect on the inside of the door. This is a normal
occurrence.

Troubleshooting

Malfunction

Possible cause

Method of elimination

The oven will not turn on

The power plug is not firmly

connected to the electrical

outlet

Remove the power plug from the

outlet. Wait 10 seconds and then

replace

Problem with power outlet

Try plugging another electrical

device into the outlet to test it

The oven will not heat

The door is not closed firmly

Close the door firmly

When the oven is operating,

the rotating glass tray makes

strange noises

The roller ring or the cooking

chamber floor is dirty

Remove the glass tray and roller

ring. Wash

the roller ring and the cooking

chamber

floor

IF THESE MEASURES DID NOT SOLVE THE PROBLEM, PLEASE APPLY TO THE
AUTHORIZED SERVICE CENTRE, REPAIR AND ADJUSTING OF THE UNIT SHOULD BE
PERFORMED ONLY BY THE QUALIFIED PERSONNEL

TECHNICAL CHARACTERISTICS

Operation conditions:

Air temperature

+10°С  +35°С

Relative air humidity

35 80%

Atmosphere pressure

86 106 kPa (650 – 800 mm of mercury)

Main parameters

Power supply:

230 V ± 10% ~ 50 Hz

Nominal microwave power

700 W

Nominal power consumption in the microwave mode

1150 W

Operation frequency

2450 ± 49 MHz

Chamber capacity

17 l

Glass tray diameter

245 mm

Dimensions, not more

450 х 360 х 260 mm

Net weight, not more

11,0 kg

Valuable material content:

GOLD

0 g

SILVER

1, 050505 g
