Remove all packing material and accessories.
Examine the oven for any damage such as
dents or broken door. Do not install if oven is
damaged.

Countertop Installation

Cabinet:

Remove any protective film found

on the microwave oven cabinet surface.

Do not remove the light brown Mica cover
that is attached to the oven cavity to
protect the magnetron.

Installation

1.

Select a level surface that provide

      enough open space for the intake
        and/or outlet vents.

A minimum clearance of 3.0 inches
(7.5cm) is required between the oven and
any adjacent walls. One side must be open.
(1)  Leave a minimum clearance of 12

inches (30cm) above the oven.

(2)  Do not remove the legs from the
       bottom of the oven.

(3)  Blocking the intake and/or outlet openings

can damage the oven.

(4)  Place the oven as far away from
       radios  and TV as  possible.
      Operation of microwave oven may
       cause interference to your radio or TV
       reception.
2.   Plug your oven into a standard household
       outlet. Be sure the voltage and the
        frequency is the same as the voltage
       and the frequency on the rating label.

WARNING:

 Do not install oven over a

range cooktop or other heat-producing
appliance. If installed near or over a heat
source, the oven could be damaged and
the warranty would be void.

Hub (underside)

Glass tray

Turntable ring assembly

3.0 inch(7.5cm)

3.0 inch(7.5cm)

12 inch(30cm)

OPEN

a.  Never place the glass tray  upside down. The glass

     tray should never be restricted.

b.  Both glass tray and turntable ring assembly must

     always be used during cooking.

c.  All food and containers of food are always placed

     on the glass tray for cooking.

d. If glass tray or turntable ring assembly cracks or

     breaks, contact your nearest authorized service

     center.

Turntable Installation

Turntable shaft
