④ AF Indicator: lights up green when there is sound input; stays off

when without sound input.

⑤

 Built-in Mic: the transmitter uses the built-in electret mic when no

external mic is connected.

⑥

 External Mic Input: standard 3.5mm TRS mic input, offers 2.5V

power supply for compatible mic.

⑦

 USB-C Port: standard USB-C port for charging.

⑧

 Transmitter Back Clip: used to fasten the product onto collar.

⑨

 Power Button: press and hold for 2s to power on/off.

⑩ Connection Indicator: flashes blue while searching for signal;

lights up solid blue when connected successfully.

⑪

Pair Button: use along with Power Button ① on the transmitter.

Press and hold to enter pairing mode on the receiver (⑩ flashes

blue), then quickly press the Power Button on the transmitter twice

to start pairing (flashes blue); wait until the automatic pairing

completes.

Note: Generally, the receiver and the transmitter are paired before

shipping out of factory.

⑫

 Volume Button: press “dB” button to cycle through 3 audio

levels. The AF indicator ④ on the receiver will flash according to the

audio output level (flashes twice at level-1, three times at level-2,

four times at level-3).

⑬

 TRS Output: standard 3.5mm TRS connector for mono/multi-

channel signal output.

⑭

Receiver Back Clip: used to fasten the product onto DSLR shoe

mount.
