CVM-V03(SIG.LAV)

FOR DSLR/

CAMCORDER

FOR

SMARTPHONE

FOR GOPRO

USER MANUAL

Foreword

Thanks for purchasing the Comica CVM-V03(SIG.LAV) lavalier
omini-directional microphone, the product is mainly designed for GoPro
sporting camera, Cellphone as well as DSLR Camera/Camcorders. It’s a
professional power-drived(which can efficiently assist to decrease the
background noise) wired and lavalier microphone.

1

Notice

Please carefully read this user manual before using;
The LED Indicator light will keep on with green color to help you check the
item or power normally work;
The product is belong to the super accurate instrument, please pay attention
to avoid any dropping, collision or thump;
Please do not put the device beside the heat or interference source, like

radiator、Roaster or air-condition, etc;

Please keep this product in the dry environment;
Do not expose this device in rain or moist environment,

2

What’

s in the box

3

Microphone

Control Body

Function Switch

Indicator Light

3.5MM Audio Plug

Windscreen

Mic Collar Bar

CR2032 Battery Tray

Windscreen

Microphone Control body’s Clamp

Cellphone Recording Cable Converter

GoPro Recording Cable Converter

Portable Case

Cable Coiling Board

CR2032 Lithium Battery

Microphone

Windscreen

Microphone

Wind Muff

Warranty Card

User Manual

Components

4

1. dB Adjustment

2. Put into Battery

Operation Instruction

5

As followed illustration: Pull the ‘Battery Door’

out , put into CR2032 battery(Note: Follow the

sign of ‘Battery Tray’ to differ ‘+’ and ‘_’

pole), then push the ‘Battery Door’ into the

Microphone body again , till so far the battery

installation is finished!

As followed illustration, move

the ‘Function Switch’ to

‘+10dB’, the dB of

microphone will be increased

from -38 to -28.

Operation Instruction

6

1. Frequency Response

（Normal dB）

（+10dB After）

Specification

8

2. Polar Pattern

Specification

9

3. Technology Parameters

Specification

10

As followed illustration: slip the WindScreen or Wind Muff over the mic by
following the arrow; The WindScreen or Wind Muff can efficiently decrease
the wind noise outdoors;

4. The usage of WindScreen and Wind Muff

3. Connection with Camera / GoPro / Cellphone / Voice Recorder

Operation Instruction

7

0

30

60

90

120

150

180

210

240

270

300

330

-45

-35

-25

-15

dB rel.1V/Pa

Polar Pattern
Maximum SPL
Frequency Range
THD
Output Impedance
Dynamic Range
Sensitivity
Battery
Input Voltage
Signal/Noise
Dimension
Battery Life

Omni-directional

≥134dB SPL (@ 1kHz, 1% THD into 1KΩ load)
20～20KHz
≤0.3%
200Ω

114dB

-28dB or- 38dB±3dB@ 1kHz

CR2032
3.0V

≥74dB SPL

36(Diameter)*12mm

≥200H

As followed illustration: you can connect the cable with Camera and

Voice Recorder directly ;

For working with Cellphone, please use the

‘Cellphone Recording

Cable’ as converter adapter;

For working with GoPro Sporting Camera, please use‘GoPro Recording

Cable’ as converter adapter;

100

1k

10k

20k

10
0.0
-10
-20
-30
-40
-50

20

dB r

e 1 v

./P

a

100

1k

10k

20k

10
0.0
-10
-20
-30
-40
-50

20

dB r

e 1 v

./P

a

LAVALIER MICROPHONE

Shenzhen Comica Technology Co.,LTD

Tel: +86-(0)755-28226496     Fax: +86-(0)755-28435621

www.comica-audio.com

Email: support@comica-audio.com
