ENGLISH

FEATURES:

•  Time in optional 12/24 hour format.

•  Daily Alarm Function

•  Snooze function(OFF or 1~60min)

•  Low battery indicate

•  Humidity: Indoor & Outdoor measurable

range: 20%RH ~ 95%RH

•  Temperature:

  — Indoor temperature measurement ranges:

-9.9°C (14.2°F) ~ 50°C (122°F)

  — Outdoor temperature measurement

ranges: -25°C (-13°F) ~ 50°C (122°F)

  — Temperature alternatively in °C or °F.

  — Outdoor thermometer ice alert

•  Maximum /minimum value record of

temperature and humidity

•  Wireless Outdoor Sensor:

  — Wall Mount or Table Stand

  — 433.92MHz RF transmitting frequency

  — 60 meter transmission range in an open

area

•  Weather forecasting function

•  Power Supply:

  Weather Station:

  Battery: 2 x LR06 AA

  Wireless Outdoor Sensor:

  Battery: 2 x LR03 AAA

MAIN UNIT APPEARANCE

Part A- LCD

(Fig. A)

A1: Weather Forecasting

A2: Outdoor Temperature

A3: Outdoor Humidity

A4: Indoor Temperature

A5: Indoor Humidity

A6: Time

Part B – Back button and power

(Fig. B)

:

B1: “SNOOZE/LIGHT” touch key

B2: “SET” button

B3: “MEM” button

B4: “+” button

B5:  “-” button

B6:  Battery compartment

WIRELESS OUTDOOR SENSOR

Part C –Wireless Outdoor Sensor

C1: Wireless Outdoor Sensor battery

compartment

Wireless remote sensor (transmitter)

•  Transmitter frequency: 433.92 MHz.

•  Range of transmission is up to 60m

(200 feet).

•  Insert the 2 batteries in to the transmitter. Pay

attention to observe the correct polarity.

INITIAL OPERATION:

•  Open the Weather Station battery

compartment cover

•  Insert 2 x AA batteries observing polarity [ “+”

and “ –“ marks]

•  When you insert the batteries, all the icon

on the LCD will light up for 3 seconds, and

you will hear a beep tone, then detect indoor

temperature & humidity.

•  The Weather Station will now start to make

a connection to the outdoor remote sensor.

This operation takes about 3 minutes and is

displayed by a flashing reception RF antenna

symbol in the “OUTDOOR” display area on

the receiver.

•  This now, Open the remote Sensor battery

compartment cover, Insert 2 x AAA batteries

observing polarity [ “+” and “–“ marks]

•  After receiver has created a connection to the

outdoor remote sensor, After 3 minutes it will

Exit RF mode.

MANUAL TIME SETTING:

•  Press and hold the “SET” button for 2

seconds, the temperature unit starts to

flash. Now use “+” and “-” buttons to set the

temperature unit in °C or °F you need.

•  Press “SET” button to confirm your setting,

the 12/24HR start to flash. Now use“+” and “-”

buttons to set the 12/24 hour mode you need.

•  Press “SET” to confirm your setting, the

Time zones start to flash, Now use“+” and “-”

buttons set a  correct time zone (-12 to +12).

•  Press “SET” to confirm your setting, the Hour

display starts to flash. Now use“+” and “-”

buttons to set the correct hour.

•  Press “SET” to confirm your setting, the

Minute display starts to flash. Now use“+” and

“-” buttons to set the correct minute.

•  Press “SET” button to confirm your setting,

the weather forecast pattern display starts to

flash. Now use“+” and “-” uttons to select the

current weather pattern.

•  Press “SET” to confirm your setting and to

end the setting procedures, Then it will return

to the normal mode.

ENGLISH

F.Y.I.:

•  If there is no valid operation within 20

seconds, it will automatically return to normal

time mode from the set mode.

Setting the daily alarms:

•  Press once “+” button, LCD display the “



” ,

the alarm function is ON. Then press once “+”

button, the “



” icon will disappears from the

display, the alarm function is OFF.

•  Press once “SET” button, LCD display alarm

time, then Press and hold “SET” button for 2

seconds until hour of the Alarm time starts to

flash. Use the “+” and “-” buttons to set the

required hour.

•  Press “SET” button to confirm your setting,

The Minute of the Alarm time starts to flash.

Use the “+” and “-” buttons to set the required

minute.

•  Press “SET” button to confirm your setting,

the snooze time of the Alarm starts to flash.

Use the “+” and “-”  buttons to set the minute

of snooze you need.

•  Press “SET” button to confirm your setting

and to end the setting procedure.

F.Y.I.:

•  If there is no valid operation within 20

seconds, it will automatically return to normal

time mode from the alarm time set mode.

•  The alarm will sound for 2 minutes if you

do not deactivate it by pressing any button.

In this case the alarm will be repeated

automatically after 24 hours.

•  Rising alarm sound (crescendo, duration: 2

minutes) changes the volume 4 times whilst

the alarm signal is heard.

Switching off the alarm signal

•  When the alarm is ringing, press any button

except the “SNOOZE/LIGHT” button to

stop the alarm signal. It is not necessary to

reactivate the alarm. It will ring again this time

next day.

Snooze function

•  When the alarm is ringing, touch the

“SNOOZE/LIGHT” button the alarm mode will

to get to SNOOZE mode. The alarm signal

sounds again after already been set.

RF Transmission Procedure:

•  The weather station automatically starts

receiving transmission from outdoor thermo

sensor for outdoor temperature & humidity

after batteries inserted. transmission

from outdoor thermo sensor for outdoor

temperature after batteries inserted.

•  The remote sensor will automatically transmit

temperature and humidity signal to the

Weather Station after batteries inserted.

•  If the Weather Station failed to receive

transmission from outdoor sensor (“- -.-”display

on the LCD), press and hold “-” button for 3

seconds to receive transmission manually. RF

icon “

” flashes on the LCD.The Weather

Station to receive the remote sensor.

Query Maximum/minimum numerical value

•  When the indoor / outdoor temperature /

humidity are shown in the LCD, The weather

station began to record temperature/humidity

maximum and minimum numerical value.

•  Press once “MEM” button, the LCD will

display maximum value of temperature/

humidity, The LCD will display the minimum

value of temperature/humidity if press once

“MEM” button again when the maximum

value is displayed.

•  at the same time, there are “MAX” or “MIN”

displayed on the LCD.

•  The temperature/humidity maximum/minimum

value will RE records after press and hold

“MEM” button 3 seconds.

F.Y.I.:

•  If the temperature reading is below ranges,

the LL.L will be displayed. If the temperature

reading is above ranges, the HH.H will be

displayed.

Ice alert

•  The ice alert symbol appears and flashing

next to the outdoor temperature when the

outdoor temperature at –1°C to + 3°C or

+30°F to + 37°F.

Weather forecasting function

•  Please take the weather forecast from your

local weather forecasting service into account

as well as the forecast from your weather

station. If there are discrepancies between

the information from your device and from the

local weather forecasting service, please take

the advice of the latter as authoritative.

•  The weather forecast is calculated base on

the following humidity & temperature data

and may deviate from the actual weather

conditions if the station in central heating

room or the humidity & temperature record is

big different from the real natural state.

Please see table 1&2
The weather station displays the following

weather symbols: sunny, light cloudy, cloudy and

rainy

The weather symbols indicate the weather

fluctuation over the next eight hours and not the

current weather.
