ENGLISH   7

ENGLISH   8

7.3 Snooze Alarm Clock Function:

 •  Press “ ALARM” button (B3) once see the alarm time (“AL” shown on the LCD):
 •  Press “Alarm” twice, to turn ON/OFF the alarm function. When alarm on,

 shown

on the LCD.

 •  When viewing alarm time, hold “ALARM” button (B3) for 3 seconds to enter the Alarm


Time setting. Press “▲” (B6) or “ ▼ ” (B7) button to adjust the alarm time, and press

“ALARM” button (B3) to confirm the setting.

 •  When alarming, press “SNOOZE/LIGHT” (B1) button to activate snooze alarm. “  ”


flash on the LCD. The alarm will snooze for 5 minutes, then it alarms again. This

snooze function can be enabled for maximum 7 times.

 •  Except “SNOOZE/LIGHT” (B1) button, press any button to stop the snooze alarm.

8.  Low batteries indication:

The low battery icon “

 ” will appear at particular channel indicating that thermo sensor

unit of the channel is in low battery status. The batteries should be replaced.

9. Projection & Backlight

 •  Press “SNOOZE/LIGHT” (B1) button, the projection and backlight shine for around 20


seconds.

 •  When DC adaptor plug in, push “PROJECTION ON/STANDBY” (B9) slide switch


to “ON”, the projection and back light will turn on and not auto off. Push the switch

to “STANDBY”, press “SNOOZE/LIGHT” (B1) button to turn on the back light and

projection for around 20 seconds.

Indoor Data:

Temperature range:

-5 to 50°C [23 to 122°F]

Temperature Units Measured:

°C or °F [switchable]

Outdoor Data:

Transmission distance: (open area)

30m @ 433MHz

Temperature range:

-40 ~ 50°C [-40 ~ 122°F]

Mount:

table

Main Unit Dimensions:

W158 x h87x d48 mm

Thermo Sensor Dimensions:

w65 x h84 x d18 mm

Battery Requirements:

Base Station [indoor]:

3 x AAA batteries

Sensors [outdoor]:

2 x AAA batteries

Adaptor Output:

DC 4.5V, 250mA

11.  Specifications

10. Precautions

 •  Use a pin to press the reset button (B4) if the Unit does not work properly.
 •  All Setting Modes will automatically exit in 15 seconds without any adjustment.
 •  Avoid placing the clock near interference sources/metal frames such as computer or


TV sets.

 •  Do not expose it to direct sunlight, heavy heat, cold, high humidity or wet areas
 •  The outdoor sensor must not be set up and installed under water. Set it up away direct


sunlight and Rain

 •  Never clean the device using abrasive or corrosive materials or products. Abrasive


cleaning agents may scratch plastic parts and corrode electronic circuits
