 •  If there is any inconsistency of weather forecast between Local Weather Station


and this unit, the Local Weather Station's forecast should prevail. We will not hold



responsible for any trouble that may come up due to wrong forecasting from this unit.

6.3  Barometric Trend Pointer (A1)



The trend pointer displayed on the LCD (A1) indicates the trend of the Barometric



pressure.

7. Thermometer

7.1 RF Transmission Procedure:

 •  The main unit automatically starts receiving transmission from outdoor thermo sensor


for outdoor temperature after batteries are inserted.

 •  The thermo sensor unit will automatically transmit temperature signal to the main unit


after batteries inserted.

 •  For having more than one external transmitter (Maximum3), select the Channel, CH1,


CH2 or CH3 to ensure each sensor is transmitting difference channel before inserting



batteries. The channel select switch (D3) is at the back of the thermo sensor.

 •  If main unit failed to receive transmission from outdoor thermo sensor in first 3 minutes


after the batteries inserted (“- - . –”display on the LCD), hold “Channel” button (B8) for



3 seconds to receive transmission manually. RF icon “ ” flashes on the LCD

Note:

Buttons  (except  “Channel”  &  “Light”  buttons)  will  not  function  while  scanning  for

thermo sensor’s signal unless they are well received or stopped manually.

Indicating the barometric

pressure trend is rising

Indicating the barometric

pressure trend is steady

Indicating the barometric

pressure trend is falling

ENGLISH   5

ENGLISH   6

5. Installation

5.1 Main Unit

The  main  unit  can  be  placed  onto  any  flat  surface  (C3),  or  wall  mounted  by  the  hanging

hole (C1) at the back of the unit.

5.2 Outdoor Thermo sensor

The remote sensor should be securely mounted onto a horizontal surface.

Note:

Transmissions  between  receiver  and  transmitter  can  reach  up  to  30m  in  open  area.

Open  Area:  there  are  no  interfering  obstacles  such  as  buildings,  trees,  vehicles,  high

voltage lines, etc.

6. Weather Forecast Function

6.1 Operation

 •  After Batteries inserted, or holding “WEATHER” button (B5) for 3 seconds, weather



icon flash (A2) on the LCD. Enter the current weather pressing “-” (B4) or “+ “(B7)



button. Press “WEATHER” (B5) button to confirm the setting. The weather forecast



may not be accurate if the current weather entered is not correct.

 •  The current weather status should be entered again if the altitude of the Main Unit is



changed. (Barometric pressure is lower at higher altitude location. Therefore, altitude



change will affect the weather forecast). The weather station will start the first forecast



at 6 hours later after the current weather status is entered.

6.2  Weather Conditions

There are totally 5 different weather status animations in the weather forecast.

Note:

 •  “                              “   is shown if the weather forecast is Rainy and outdoor





                    temperature (any channel) under 0°C.

Sunny

Rain

Freezing or Snow

SlightyCloudy

Cloudy

Freezing or Snow
