Appendix
5-1-2 Configuring JMB362/GIGABYTE SATA2 SATA Controllers
A. Installing SATA hard drive(s) in your computer
Attach one end of the SATA signal cable to the rear of the SATA hard drive and the other end to available
SATA port on the motherboard. See the table below for the SATA controllers and their corresponding SATA
ports. Then connect the power connector from your power supply to the hard drive.
B. Configuring SATA controller mode in BIOS Setup
Make sure to configure the SATA controller mode correctly in system BIOS Setup.
Step 1:
Turn on your computer and press <Delete> to enter BIOS Setup during the POST. In BIOS Setup, go to
Inte-
grated Peripherals
. To enable RAID, see the table below for configuring different SATA controllers for RAID.
The BIOS Setup menus described in this section may differ from the exact settings for your moth-
erboard. The actual BIOS Setup menu options you will see shall depend on the motherboard you
have and the BIOS version.
Figure 1
Step 2:
Save changes and exit BIOS Setup.
Controller Connectors
BIOS Settings
JMB362
eSATA ports
Set
eSATA Controller
to
Enabled
Set
eSATA Ctrl Mode
to
RAID
JMB362
GSATA2_0/1
Set
GSATA 0_1 Controller
to
Enabled
Set
GSATA 0_1 Ctrl Mode
to
RAID
GIGABYTE GSATA2_2/3
Set
GSATA 2_3/IDE Controller
to
Enabled
SATA2
Set
GSATA 2_3/IDE Ctrl Mode
to
RAID/IDE
CMOS Setup Utility-Copyright (C) 1984-2009 Award Software
Integrated Peripherals
higf
: Move
Enter: Select
+/-/PU/PD: Value
F10: Save
ESC: Exit
F1: General Help
F5: Previous Values
F6: Fail-Safe Defaults
F7: Optimized Defaults
Item Help
Menu Level
USB Legacy Function
[Enabled]
USB Storage Function
[Enabled]
Azalia Codec
[Auto]
PCI Express x4/x1 Slot
[Auto]
Onboard H/W 1394
[Enabled]
Onboard H/W LAN1
[Enabled]
Onboard H/W LAN2
[Enabled]
Green LAN
[Disabled]
SMART LAN1
[Press Enter]
SMART LAN2
[Press Enter]
Onboard LAN1 Boot ROM
[Disabled]
Onboard LAN2 Boot ROM
[Disabled
eSATA Controller
[Enabled]
eSATA Ctrl Mode
[RAID]
GSATA 0_1 Controller
[Enabled]
GSATA 0_1 Ctrl Mode
[RAID]
GSATA 2_3/IDE Controller
[Enabled]
GSATA 2_3/IDE Ctrl Mode
[RAID/IDE]
Onboard Serial Port 1
[3F8/IRQ4]
