BIOS Setup

- 38 -

  Bi-Directional PROCHOT

 (Note)

Auto

Lets the BIOS automatically configure this setting. (Default)

Enabled   When the CPU or chipset detects that an overheating is occurring, PROCHOT signals will

be emitted to lower CPU performance to decrease heat production.

Disabled   Only allows the CPU to detect whether an overheating is occurring to emit PROCHOT

signals.

>>>>>   Standard Clock Control

  BCLK/DMI/PEG Clock Control

Enables or disables the control of CPU base clock and DMI/PCIe bus frequency.

Enabled

 will allow the

BCLK/DMI/PEG Frequency(0.1MHz)

 item below to be configurable. Note: If your system fails to boot

after overclocking, please wait for 20 seconds to allow for automated system reboot, or clear the CMOS
values to reset the board to default values. (Default: Disabled)

  BCLK/DMI/PEG Frequency(0.1MHz)

Allows you to manually set the CPU base clock and DMI/PCIe bus frequency. The adjustable range is

from 800 MHz to 2000 MHz. This item is configurable only when the

BCLK/DMI/PEG Clock Control

 op-

tion is enabled.

Important:

 It is highly recommended that the CPU frequency be set in accordance with the CPU specifications.

  System Memory Multiplier (SPD)

Allows you to set the system memory multiplier.

Auto

 sets memory multiplier according to memory SPD

data. (Default: Auto)

  Memory Frequency(Mhz)

The first memory frequency value is the normal operating frequency of the memory being used; the

second is the memory frequency that is automatically adjusted according to the

BCLK/DMI/PEG

Frequency(0.1MHz)

and

System Memory Multiplier

 settings.

  Internal Graphics Clock

Allows you to set the onboard graphics clock. The adjustable range is from 0 MHz to 3000 MHz. (Default:
Auto)

(Note)   This item is present only if you install a CPU that supports this feature. For more information about

Intel CPUs' unique features, please visit Intel's website.
