BIOS Setup
- 38 -
System Memory Multiplier (SPD)
Allows you to set the system memory multiplier.
Auto
sets memory multiplier according to memory SPD
data. (Default: Auto)
Memory Frequency(Mhz)
The first memory frequency value is the normal operating frequency of the memory being used; the
second is the memory frequency that is automatically adjusted according to the
BCLK Frequency(Mhz)
and
System Memory Multiplier
settings.
Internal Graphics Clock
Allows you to set the onboard graphics clock. The adjustable range is from 400 MHz to 2000 MHz. (Default:
Auto)
PCI Express Frequency(Mhz)
Allows you to manually set the PCIe clock frequency. The adjustable range is from 90 MHz to 150 MHz.
Auto
sets the PCIe clock frequency to standard 100 MHz. (Default: Auto)
>>>>> Advanced Clock Control
CPU Clock Drive
Allows you to adjust the amplitude of the CPU and the Chipset clock.
Options are: 700mV, 800mV, 900mV (default), 1000mV.
PCI Express Clock Drive
Allows you to adjust the amplitude of the PCI Express and Chipset clock.
Options are: 700mV, 800mV, 900mV (default), 1000mV.
CPU Clock Skew
Allows you to set the CPU clock prior to the Chipset clock.
Options are: 0ps~750ps. (Default: 0ps)
PCH Clock Skew
Allows you to set the Chipset clock prior to the CPU clock.
Options are: 0ps~750ps. (Default: 0ps)
Advanced Memory Settings
CMOS Setup Utility-Copyright (C) 1984-2010 Award Software
Advanced Memory Settings
higf
: Move
Enter: Select
+/-/PU/PD: Value
F10: Save
ESC: Exit
F1: General Help
F5: Previous Values
F6: Fail-Safe Defaults
F7: Optimized Defaults
Item Help
Menu Level
Extreme Memory Profile (X.M.P.)
(Note)
[Disabled]
System Memory Multiplier
(SPD)
[Auto]
Memory Frequency (Mhz)
1333
1333
Performance Enhance
[Turbo]
DRAM Timing Selectable
(SPD)
[Auto]
Profile DDR Voltage
1.5V
Profile QPI Voltage
1.15V
>>>>> Channel A
Channel A Timing Settings
[Press Enter]
>>>>> Channel B
Channel B Timing Settings
[Press Enter]
(Note) This item appears only if you install a memory module that supports this feature.
