Philips QT4020/60 - Инструкция по эксплуатации - Страница 2

Lietuviškai

introduction

Congratulations on your purchase and welcome to

Philips! To fully benefit from the suppor t that Philips offers,

register your product at www.philips.com/welcome.

important

Read this user manual carefully before you use the

appliance and save it for future reference.

Danger

Make sure the adapter does not get wet.

Warning

The adapter contains a transformer. Do not cut

off the adapter to replace it with another plug, as

this causes a hazardous situation.

Check if the voltage indicated on the appliance

corresponds to the local mains voltage before you

connect the appliance.

This appliance is not intended for use by persons

(including children) with reduced physical, sensor y

or mental capabilities, or lack of experience and

knowledge, unless they have been given super vision

or instruction concerning use of the appliance by a

person responsible for their safety.

Children should be super vised to ensure that they

do not play with the appliance.

Caution

Use, charge and store the appliance at a temperature

between 15°C and 35°C.

Only use the adapter supplied.

Never immerse the appliance in water or rinse it

under the tap.

If the adapter is damaged, always have it replaced

with one of the original type in order to avoid a

hazard.

This appliance is only intended for trimming the

human beard. Do not use it for any other purpose.

Do not use the appliance if the cutting unit is

damaged or broken, as this may cause injur y.

Electromagnetic fields

This Philips appliance complies with all standards

regarding electromagnetic fields (EMF). If handled

properly and according to the instructions in this user

manual, the appliance is safe to use based on scientific

evidence available today.

Charging

Charge the appliance fully before you use it for the first

time.

It takes approximately 10 hours to fully charge the

batter y.

A fully charged appliance has a cordless trimming time of

up to 35 minutes.

Note: The appliance does not run from the mains. When the

battery is empty, charge it as described below.

  1

  Make sure the appliance is switched off (Fig. 1).

  2

  Insert the appliance plug into the appliance (Fig. 2).

  3

  Put the adapter in the wall socket.

The green light on the adapter goes on to indicate

that the appliance is charging.  (Fig. 3)

Do not charge the appliance for more than 24 hours.

Optimising the lifetime of the battery

When the appliance has been charged for the first time,

we advise you to use it until the batter y is completely

empty.

Do not recharge the appliance in between the trimming

sessions.

Continue to use the appliance until the motor almost

stops running during a session. Then recharge the batter y.

Follow this procedure at least twice a year.

trimming

Always comb the beard and/or moustache with a fine

comb before you star t trimming.

When you trim for the first time, be careful. Do not

move the trimmer too fast. Make smooth and gentle

movements.

Trimming with beard trimming comb

  1

  Turn the Precision Zoom Lock

`

 to the desired

hair length setting.  (Fig. 4)

-

-

-

-

-

-

-

-

-

-

-

,

See the table below for an over view of the hair length

settings and the corresponding hair lengths.

Setting

Resulting hair length

1

1.5mm

2

2.5mm

3

4mm

4

5.5mm

5

7.5mm

6

9.5mm

7

12mm

8

15mm

9

19mm

The setting appears in the window below the Precision
Zoom Lock

`

.

Note: When you trim for the first time, start at the highest

setting (9) to familiarise yourself with the appliance.

  2

  Switch on the appliance.

  3

  To trim in the most effective way, move the

trimmer against the direction of hair growth.

Make sure the surface of the comb always stays in

contact with the skin (Fig. 5).

  4

  If a lot of hair has accumulated in the comb, remove

the beard trimming comb and blow and/or shake

the hair out of the comb. The selected hair length

setting does not change when you do this (Fig. 6).

Trimming with the unique ‘stubble look’

setting

  1

  To create a ‘stubble look’, trim with the beard

trimming comb set to hair length setting 1 (Fig. 7).

Trimming without beard trimming comb

Use the trimmer without beard trimming comb to trim

full beards and single hairs.

  1

  Pull the comb off the appliance to remove it (Fig. 8).

Never pull at the flexible top of the beard

trimming comb. Always pull at the bottom part.

  2

  Switch on the appliance.

  3

  Make well-controlled movements. Touch the hair

lightly with the trimmer (Fig. 9).

Cleaning

Never use scouring pads, abrasive cleaning agents or

aggressive liquids such as alcohol, petrol or acetone to

clean the appliance.

  1

  Make sure the appliance is switched off and

disconnected from the mains before you clean it.

  2

  Remove the beard trimming comb.

  3

  Open the cutting unit (Fig. 10).

  4

  Clean the cutting unit and the inside of the

appliance with the cleaning brush supplied (Fig. 11).

  5

  Push the cutting unit back onto the appliance to

close it (‘click’) (Fig. 12).

Note: The appliance does not need any lubrication.

Replacing the cutting unit

Only replace a worn or damaged cutting unit with an

original Philips cutting unit, available from authorised

Philips ser vice centres.

  1

  Open the cutting unit.

  2

  Pull the old cutting unit upwards to remove

it (Fig. 13).

  3

  Insert the two lugs of the new cutting unit into the

guiding slots (Fig. 14).

  4

  Push the cutting unit back onto the appliance

(‘click’) (Fig. 12).

environment

Do not throw away the appliance with the normal

household waste at the end of its life, but hand it in

at an official collection point for recycling. By doing

this, you help to preser ve the environment (Fig. 15).

The built-in rechargeable batter y contains substances

that may pollute the environment. Always remove

the batter y before you discard and hand in the

appliance at an official collection point. Dispose of

the batter y at an official collection point for batteries.

If you have trouble removing the batter y, you can

also take the appliance to a Philips ser vice centre. The

staff of this centre will remove the batter y for you

and will dispose of it in an environmentally safe way.

  1

  Disconnect the appliance from the mains and let

the appliance run until the motor stops.

  2

  Undo the screw in the housing of the

trimmer (Fig. 16).

  3

  Separate the 2 housing parts with a

screwdriver (Fig. 17).

  4

  Insert the screwdriver into the small slot in the

printed circuit board marked with an arrow. Push

the screwdriver down until parts of the printed

circuit board break off (Fig. 18).

  5

  Remove the battery holder including the

rechargeable battery (Fig. 19).

  6

  Separate the rechargeable battery from the battery

holder (Fig. 20).

Do not connect the appliance to the mains again after it

has been opened!

Guarantee & service

If you need ser vice or information or if you have a

problem, please visit the Philips website at

www.philips.com

 or contact the Philips Consumer Care

Centre in your countr y (you find its phone number in

the worldwide guarantee leaflet). If there is no Consumer

Care Centre in your countr y, go to your local Philips

dealer.

-

-

4203.000.5536.2

2/9
