K

L

M

Adaptor

Use this to connect the trimmer
to an AC power source for re-
charging or for AC operation.

N

Oil

Lubricate the space between the
stationary and moving blade with
2 or 3 drops of oil after use. (see
fig. 16)

O

Cleaning Brush

READ ALL INSTRUCTIONS BE-
FORE USE.

Operation

Charging and cordless trimming

When charging the beard/hair trim-
mer for the first time or when it has
not been in use for more than 6
months, charge it for the activation
for at least 16 hours before use.
Connect the power cord to the beard/
hair trimmer, and plug the adaptor to
an AC outlet.
In some areas, a special plug adap-
tor may be required.

The charge indicator lamp will glow
red and it will stay on until the adap-
tor is disconnected from the AC out-
let. (see fig. 4)
You can fully charge the trimmer in 8
hours if it seems to be losing speed.
A full charge will supply enough
power for approx. 10 trims (5 minutes
per trim for a normal beard).

AC operation

Connect the AC adaptor to the body
in the same way as for charging, and
set the switch to “1” to use the trim-
mer.
If the trimmer does not operate after
connection as mentioned above, re-
turn switch to “0•charge” position for
1 minute and then set switch back to
“1” position.

Trimming of beard

Place the angled face of the comb
against the skin and cut the beard
by moving the trimmer in all direc-
tions to obtain a uniform cut. (see fig.
5)
With curly facial hair, the comb at-
tachment may not cut all of the hair.
In this case, remove the comb attach-
ment and use a conventional comb
to draw out the remaining uncut, hair.
(see fig. 6)
When shaping the beard, remove the
comb attachment. Place the angled
edge against the skin and make the
border of the beard even.

Thinning Plate

When thinning, slide the thinning
plate up until it firmly clicks in
position. (see fig. 7)

Thinning Plate Lock Button

Press and hold while sliding the
Thinning plate down to set the
Thinning Plate back to its original
position.

This Beard/Hair Trimmer is for the
trimming and care of mustaches,
beards and hair. Trimming length can
be adjusted between 1 to 20 mm. The
trimmer can be operated either from
an AC power source or on its own
rechargeable battery.

Parts identification

(see fig. 1)

A

Switch

Slide up to turn on, slide down to
turn off.

B

Charge Indicator Lamp

Lights when the unit is connected
with the adaptor

 to an AC

power source for charging.

C

Main Blade

A precision 39 mm-wide blade
which can be used with the comb
attachment

F

M

.

D

Quick Adjust Dial

Turn the dial to a higher setting to
raise or lower the comb attach-
ment

F

 to the desired length (be-

tween 1 and 20 mm) (see fig. 2).
The comb attachment is locked
in position when the switch is set
to “1”.

E

Trimming Length Indicator

Indicator

Trimming Length

1

1.0 mm

2

2.0 mm

•

3.5 mm

5

5.0 mm

•

6.5 mm

8

8.0 mm

•

9.5 mm

11

11.0 mm

•

12.5 mm

14

14.0 mm

•

15.5 mm

17

17.0 mm

•

18.5 mm

20

20.0 mm

• The actual hair length may be

longer than the set trimming length.

F

Comb Attachment

Use this to control the trimming
length. (see fig. 3)

G

Moving Blade

H

Stationary Blade

I

Cleaning Lever

Push this lever to remove bits of
hair caught between the station-
ary blade and the moving blade.

J

Blade Block

Release to remove the blade
block from the housing to clean
or replace the blade. (see fig. 12)

7

6
