Configuration

Once logged in, we recommend clicking the  “Check  for  updates”  button  in the  QuickSet menu, as  updating your
RouterOS  software  to the latest  version ensures  the best performance and stability.  For  wireless  models, please
make sure you have selected the country where the device will be used, to conform with local regulations.

RouterOS   includes   many  configuration   options   in   addition   to   what   is   described   in  this   document.  We  suggest   to
start here to get yourself accustomed to the possibilities:

http://mt.lv/help

. In case IP connection is not available, the

Winbox tool (

http://mt.lv/winbox

) can be used to connect to the MAC address of the device from the LAN side (all

access is blocked from the Internet port by default).

For recovery purposes, it is possible to boot the device for reinstallation, see section

Buttons and jumpers

.

Mounting

It   is   possible   to  attach   the   device   to   a   wall,   using  the   provided   screw   holes   on  the   back   of   the   unit.  The   device
should be mounted in a way that the cable openings are pointing downward.

The IP rating scale for this device is IPX0. The device has no protection from water contamination, please ensure
the placement of the device in a dry and ventilated environment.

We recommend Cat5/6 shielded cables for our devices.

Mounting and configuration of this device should be done by a qualified person.

The enclosure includes a grounding screw hole with an M4 thread (screw not included). In locations with the risk of
ESD discharge, you are encouraged to connect the grounding screw to verified grounding infrastructure.

This equipment should be installed and operated with a minimum distance of 20 cm between the device and your
body. Operation of this equipment in the residential environment could cause radio interference.

Extension slots and ports

The  Ethernet  ports  are   connected  in  two  groups  of   five,  each  group  is   connected  through  a  switch  chip.
The   ports   can   be   configured   individually   and   support   automatic   cross/straight   cable   correction   (Auto
MDI/X), so you can use either straight or cross-over cables for connecting to other network devices.

SFP+ port accepts SFP and SFP+ modules. Note: The RB4011 does not support passive DAC modules,
1GB copper SFP modules and SFP GPON modules.

RJ45 console port for serial console access, set by default to 115200 bit/s, 8 data bits, 1 stop bit, no parity.

An Integrated wireless module which supports AP/CPE/P2P/repeater modes.

5 GHz 802.11a/n/ac.

2.4 GHz 802.11b/g/n.

Buttons and jumpers

The reset button has the following functions:

Hold   this   button   during   boot   time   until   LED   light   starts   flashing,   release   the   button   to   reset   RouterOS
configuration (total 5 seconds).

Keep holding for 5 more seconds, LED turns solid, release now to turn on CAP mode. The device will now
look for a CAPsMAN server (total 10 seconds).

Or Keep holding the button for 5 more seconds until LED turns off, then release it to make the
RouterBOARD look for Netinstall servers connected to its first Ethernet port (total 15 seconds).

Regardless of the above option used, the system will load the backup RouterBOOT loader if the button is pressed
before power is applied to the device. Useful for RouterBOOT debugging and recovery.

See mikrotik.com/products for the latest version of this document.

Document #50324 Modified on: 28.JUN.2019
