Instruction manual

4

Headphone connection

• For private listening, insert 3.5 mm

headphone into the stereo headphone jack.

• Adjust volume control to the appropriate

level as desired.

• When the stereo headphone jack is

plugged, speaker will disconnect automatically.

Radio operation

• Press repeatedly MODE button until the

display shows FM.

• Press and hold

 button or

 button;

the fast scanning starts. The frequency will
continue to change and will automatically stop
when a broadcast station is received.

• To receive a weak broadcast signal shortly

press

 button or

 button and adjust the

frequency you wish to receive step-by-step.

Saving stations to memory

• In radio mode, press and hold PLAY/

PAUSE button, the unit will search and save all
available radio stations.

• Press PRE.+ or PRE.- to cycle through the

all saved stations.

Antenna

• For FM reception, adjust the telescopic

antenna appropriately to obtain the best
reception on the band selected.

USB/SD operations

Playback

• Turn on the device

• Insert a USB device into the USB port or

SD card into the slot. The unit will switch to

USB/SD mode automatically and the USB/SD

icon will show in the top of the display. Or, if

afterwards you selcted another mode, press

MODE button repeatedly to select USB/SD

mode.

• Playback of the first track will start

automatically. The display will show PLAY icon

in the top and the number of the track.

• Press PLAY/PAUSE button to pause

playback. Press the button again to resume

playback.

• Press repeatedly

 button or

 button

to go to next or previous track. Press and

hold

/

 buttons for backward or forward

searching; release the button for normal

playback.

• Press ALBUM+/ALBUM- buttons to select

next or previous albums or folders.

• Press and hold the MODE button once

to repeat the currently playing track. Press

and hold the MODE button twice to repeat the

whole album/folder.

General USB/SD notes

  According to the USB 1.1/2.0 Standard,

usage of a USB device with power current

consumption exceeding 500 mA is not

recommended without supplementary power

supply. Failure to use supplementary power for

connected USB drives with power consumption

exceeding this value as well as defective

USB drives may cause mechanical or thermal

changes of elements of this unit as well as

failure of internal elements of the USB port.

Such damages are not warrantee cases.

Warning: usage of external USB drives

containing BIN files in the root directory may

cause malfunction of the unit or damage to the

software.

• This unit is equipped with a USB socket

that can accept and play MP3 files stored on

standard USB flash (2.0 version)/SD cards up

to 32 GB.

• FAT and FAT32 file system are supported

by this unit.

AUX jack

You can connect the audio output of an

external device to this unit, to listen to the sound
of that device through the speakers of this unit.

• To connect an external audio device,

please use a standard audio cable with 3.5-mm-
to-3.5 mm plugs (not included) to connect the
headphone out or audio line-out of the external
