5

Instruction manual

5

General USB/SD notes

  According to the USB 1.1/2.0 Standard,

usage of a USB device with power current

consumption exceeding 500 mA is not

recommended without supplementary power

supply. Failure to use supplementary power for

connected USB drives with power consumption

exceeding this value as well as defective

USB drives may cause mechanical or thermal

changes of elements of this unit as well as

failure of internal elements of the USB port.

Such damages are not warrantee cases.

AUX jack

Warning: usage of external USB drives

containing BIN files in the root directory may

cause malfunction of the unit or damage to the

software.

You can connect the audio output of an

external device to this unit, to listen to the sound
of that device through the speakers of this unit.

• To connect an external audio device, please
use a standard audio cable with 3.5-mm-to-3.5
mm plugs (not included) to connect the headphone
out or audio line-out of the external device to
the AUX input socket of this unit.

• Press FUNCTION button repeatedly to select
AUX mode; AUX icon will be displayed.
• Turn on the external device. You cannot control

playback with the buttons of this unit except

adjusting the volume.

• This unit is equipped with a USB socket

that can accept and play MP3 files stored on

standard USB flash (2.0 version)/SD cards up

to 32 GB.

• FAT and FAT32 file system is supported by

this unit.

Bluetooth operation

Bluetooth wireless playback

• This unit can wirelessly playback audio

from any device with Bluetooth A2DP
function.

• The wireless range is approximately within

10 meters.

• Wireless audio streaming requires pairing

of a Bluetooth device (e.g. smartphone).

HOW TO PAIR YOUR DEVICE TO THIS

UNIT:

•

M

ake sure the Bluetooth function is

switched on in your device (e.g. smartphone,
tablet).

• Switch on the unit and press the

FUNCTION button repeatedly until
the display shows BT.

• You will find the unit listed in the

Bluetooth connections list of your device (as
TF-SRP3461B).

• If asked for a passcode, enter “0000”
• The initial setup is required only once

per device.

• After a successful pairing, you can

control the playback of audio files as
described in the USB/SD operation section.
