Instruction manual

6

USB operations

Playback

• Turn on the device

• Insert a USB device into the USB port

Press the FUNCTION button to select the

USB mode.

• Press PLAY/PAUSE button to pause

playback. Press the button again to resume

playback. Press STOP to stop playback.

• Press repeatedly SKIP+ or SKIP-

to go to next or previous track. Press and

hold these buttons for backward or forward

searching; release the button for normal

playback.

• Playback modes and programming

are as the same as that of CD / MP3.

Please refer to CD/MP3 operation.

General USB notes

  According to the USB 1.1/2.0 Standard,

usage of a USB device with power current

consumption exceeding 500 mA is not

recommended without supplementary power

supply. Failure to use supplementary power for

connected USB drives with power consumption

exceeding this value as well as defective

USB drives may cause mechanical or thermal

changes of elements of this unit as well as

failure of internal elements of the USB port.

Such damages are not warrantee cases.

Warning: usage of external USB drives

containing BIN files in the root directory may

cause malfunction of the unit or damage to the

software.

• This unit is equipped with a USB socket

that can accept and play MP3 files stored on

standard USB flash (2.0 version) up to 32

GB.

• FAT and FAT32 file system are supported

by this unit.

• Playback of the first track will start

automatically. The display will show "USB".

Bluetooth operations

Bluetooth wireless playback

• This unit can wirelessly playback audio

from any device with Bluetooth A2DP
function.

• The wireless range is approximately within

10 meters.

• Wireless audio streaming requires pairing

of a Bluetooth device (e.g. smartphone).

HOW TO PAIR YOUR DEVICE TO THIS

UNIT:

• Make sure the Bluetooth function is

switched on in your device (e.g. smartphone,
tablet).

• Switch on the unit and press

FUNCTION to select the Bluetooth mode.

• Once the Bluetooth pairing indicator

begins flashing, you will find the unit listed in
the Bluetooth connections list of your device
(as TF-CSRP3

500

B).

• If asked for a passcode, enter “0000”
• The initial setup is required only once

per device. To pair another device repeat the
above steps.

AUX

You can connect the audio output of an

external device to this unit, to listen to the sound
of that device through the speakers of this unit.

• To connect an external audio device,

please use a standard audio cable with 3.5-
mm-to-3.5 mm plugs (not included) to connect
the headphone out or audio line-out of the
external device to the AUX input socket.

• Select the AUX mode using the

FUNCTION button.

• Turn on the external device. You cannot

control playback with the buttons of this unit
except adjusting the volume.
