Instruction manual

4

•  Close the battery compartment cover.

AC operation

•  Before the first connecting of the appliance

check that voltage indicated on the rating label
corresponds the mains voltage in your home.

•  Plug the corresponding end of cord into

the AC socket on the rear of the set.

•  Insert the plug into power supply.
Caution:
•  When the set is only used with AC or is

not used for 2 weeks or more, please remove
the batteries, to avoid damage to the set from
leakage of batteries.

•  Always switch off the unit when not in use.
•  Always unplug the appliance from power

supply, when no use long time.

Headphone jack

•  For private listening, insert 3.5 mm

headphone into the stereo headphone jack.

•  Adjust volume to the appropriate level as

desired.

•  When the stereo headphone jack is

plugged, speaker will disconnect automatically.

AUX line in jack

You can connect the audio output of an

external device (such as a CD-player) to
this unit, to listen to the sound of that device
through the amplifier of this unit.

•  To connect an external audio device (eg.

MP3 player), please use a standard stereo
cable (not included) with 3.5 mm to 3.5 mm
plugs to connect the headphone out or audio
line-out of the external device to the AUX input
socket of this unit.

•  Slide the function switch to AUX position.
•  Turn on the external device.

Radio operation

•  Set the function switch to RADIO position.
•  Select your desired broadcasting band by

setting the band switch to the desired position.
AM of FM will be displayed.

•  Rotate TUNING regulator to tune to your

desired radio station frequency. The radio
frequency will be shown on the display.

•  Rotate VOL+/- regulator to adjust sound

volume level.

•  To turn off the radio set the function switch

to AUX position.

Antenna

•  For FM reception, adjust the telescopic

antenna appropriately to obtain the best
reception on the band selected.

•  The AM signals are picked up through the

built-in antenna. The set should be placed to
an appropriate position for the best reception.

FM stereo reception

•  In particular when stereo signal is weak

and much noise are received, it is preferable
to receive programs in mono mode. Set the
band switch to FM ST position to receive radio
programs in stereo mode.

•  If the program is received in FM stereo, the

FM stereo indicator will light up.

Disc operations

Insertion and removal of discs

•  Press the CD compartment OPEN/CLOSE

button to open the compartment. Place a
disc into the compartment with the label-side
(printed side of disc) facing upwards.

•  When the disc has been placed onto

the center spindle, gently lower the CD-door
downwards until it locks shut. The disc is now
ready to be played.

•  When opening the CD-door, always

ensure the disc is not in motion (not spinning).
