AUX IN, RCA OUT, SUB OUT&Video OUT

Auxiliary Input

The Auxiliary Input Jack is on the rear of unit. Insert the RCA plugs into the AUX IN jack on the front of the unit.
Route the other end of the RCA to the any external audio device such as walkman and discman. Press and hold the
Mode button to choose AUX. Use the volume control to adjust volume.

RCA Output

The RCA Output Jack is on the back of the unit. (Refer to Wiring Diagram) This output is for connecting amplifier,
equalizer, or other audio componement that requires a pre-amp out connection. (Red = Right, White = Left) Follow
the manufacturers instructions for the audio component that you are connecting.

Subwoofer Output

The Subwoofer Output Jack is on the back of the unit, (refer to wiring diagram). This output is for connecting
subwoofer that requires a pre-amp out connection. This is a mono output. Follow the manufacturers instructions for
the audio component that you are connecting. This function can only be activated during Disc Playback. If you want
to have subwoofer turned on for RADIO mode, you have to do it in DISC or AUX mode first.

Video Output: 1&2

The Video Output Jack is on the back of the unit. (Refer to Wiring Diagram) This output (in yellow) is for connecting
monitor(s). You must connect a monitor for car in order to play this unit in VCD. Consult your dealer for any kinds
of monitors that are suitable to use in car. Since there are two yellow jacks, you can connect up to 2 monitors and
they can play the same graphics at the same time. Press the  BAND / P/N  to choose between PAL and NTSC mode.
