Specifications

Cassette Player section

Tape track

4-track 2-channel stereo

Wow and flutter

0.08 % (WRMS)

Frequency response

30 – 18,000 Hz

Signal-to-noise ratio

Tuner section

FM

Tuning range

FM1/FM2:
87.5 – 108 MHz
(at 50 kHz step)
FM3:
65 – 74 MHz
(at 30 kHz step)

Aerial terminal

External aerial connector

Intermediate frequency

10.7 MHz/450 kHz

Usable sensitivity

9 dBf

Selectivity

75 dB at 400 kHz

Signal-to-noise ratio

67 dB (stereo),
69 dB (mono)

Harmonic distortion at 1 kHz

0.5 % (stereo),
0.3 % (mono)

Separation

35 dB at 1 kHz

Frequency response

30 – 15,000 Hz

AM

Tuning range

531 – 1,602 kHz

Aerial terminal

External aerial connector

Intermediate frequency

10.7 MHz/450 kHz

Sensitivity

30 µV

Power amplifier section

Outputs

Speaker outputs
(sure seal connectors)

Speaker impedance

4 – 8 ohms

Maximum power output

50 W

×

 4 (at 4 ohms)

General

Outputs

Audio outputs (rear)
Power aerial relay control
lead
Power amplifier control lead

Inputs

Telephone ATT control
terminal
BUS control input terminal
BUS audio input terminal
Remote controller input
terminal
Aerial input terminal

Tone controls

Low:
±10 dB at 60 Hz (XPLOD)
Mid:
±10 dB at 1 kHz (XPLOD)
High:
±10 dB at 10 kHz (XPLOD)

Power requirements

12 V DC car battery
(negative earth)

Dimensions

Approx. 178

×

 50

×

 180 mm

(w/h/d)

Mounting dimensions

Approx. 182

×

 53

×

 161 mm

(w/h/d)

Mass

Approx. 1.2 kg

Supplied accessories

Card remote commander
RM-X114
Parts for installation and
connections (1 set)
Front panel case (1)

Optional accessories

Rotary commander
RM-X4S
BUS cable (supplied with
an RCA pin cord)
RC-61 (1 m), RC-62 (2 m)

Optional equipment

CD changer (10 discs)
CDX-757MX, CDX-656X
CD changer (6 discs)
CDX-T70MX, CDX-T69X
MD changer (6 discs)
MDX-66XLP
MG-MS System-up Player
MGS-X1
DVD changer
DVX-100S
Source selector
XA-C30
AUX-IN Selector
XA-300

Note
This unit cannot be connected to a digital preamplifier
or an equalizer which is Sony BUS system compatible.

Design and specifications are subject to change
without notice.

Cassette type

TYPE II, IV

61 dB

TYPE I

58 dB
