18

Specifications

Cassette Player section

Tape track

4-track 2-channel stereo

Wow and flutter

0.08 % (WRMS)

Frequency response

30 – 18,000 Hz

Signal-to-noise ratio

Tuner section

FM

Tuning range

FM tuning interval:
87.5 – 108.0 MHz

Aerial terminal

External aerial connector

Intermediate frequency

10.7 MHz

Usable sensitivity

11 dBf

Selectivity

75 dB at 400 kHz

Signal-to-noise ratio

65 dB (stereo),
68 dB (mono)

Harmonic distortion at 1 kHz

0.7 % (stereo),
0.5 % (mono)

Separation

33 dB at 1 kHz

Frequency response

30 – 15,000 Hz

AM

Tuning range

AM tuning interval:
531 – 1,602 kHz

Sensitivity

30 µV

Aerial terminal

External aerial connector

Intermediate frequency

10.7 MHz/450 kHz

Power amplifier section

Outputs

Speaker outputs
(sure seal connectors)

Speaker impedance

4 – 8 ohms

Maximum power output

50 W

×

 4 (at 4 ohms)

General

Outputs

Audio outputs
Power aerial relay control
lead
Power amplifier control lead

Inputs

BUS control input terminal
BUS audio input terminal
Aerial input terminal

Tone controls

Bass ±9 dB at 100 Hz
Treble ±9 dB at 10 kHz

Power requirements

12 V DC car battery
(negative earth)

Dimensions

Approx. 178

×

 50

×

 178

mm (w/h/d)

Mounting dimensions

Approx. 182

×

 53

×

 161

mm (w/h/d)

Mass

Approx. 1.2 kg

Supplied accessories

Parts for installation and
connections (1 set)
Front panel case (1)

Optional accessories

BUS cable (supplied with
an RCA pin cord)
RC-61 (1 m), RC-62 (2 m)

Optional equipment

CD changer (6 discs)
CDX-T70MX, CDX-T69
MD changer (6 discs)
MDX-66XLP
MG Memory Stick
System-up Player
MGS-X1
Source selector
XA-C30

Note
This unit cannot be connected to a digital preamplifier
or an equalizer.

Design and specifications are subject to change
without notice.

Cassette type

TYPE II, IV

61 dB

TYPE I

58 dB
