JVC KD-DV4207 - Инструкция по эксплуатации - Страница 34

ENGLISH

34

Specifications

AUDIO AMPLIFIER SECTION

Maximum Power Output: Front/Rear:

50 W per channel

Continuous Power Output
(RMS):

Front/Rear:

19 W per channel into 4 Ω, 40 Hz to
20 000 Hz at no more than 0.8% total
harmonic distortion

Load Impedance:

4 Ω (4 Ω to 8 Ω allowance)

Tone Control Range:

Bass/Treble:

±10 dB at 100 Hz/±10 dB at 10 kHz

Frequency Response:

40 Hz to 20 000 Hz

Signal-to-Noise Ratio:

70 dB

Audio Output Level:

Digital (DIGITAL OUT: Optical):

Signal wave length: 660 nm
Output level: –21 dBm to –15 dBm

Line-Out Level/Impedance:

2.0 V/20 kΩ load (full scale)

Output Impedance:

1 kΩ

Color System:

PAL

Video Output (composite):

1 Vp-p/75 Ω

Other Terminals:

CD changer

TUNER SECTION

Frequency Range:

FM1 /FM2:

87.5 MHz to 108.0 MHz

FM3:

65.00 MHz to 74.00 MHz

AM:

(MW)

522 kHz to 1 620 kHz

(LW)

144 kHz to 279 kHz

FM Tuner

Usable Sensitivity:

11.3 dBf (1.0 μV/75 Ω)

50 dB Quieting Sensitivity:

16.3 dBf (1.8 μV/75 Ω)

Alternate Channel Selectivity
(400 kHz):

65 dB

Frequency Response:

40 Hz to 15 000 Hz

Stereo Separation:

30 dB

MW Tuner

Sensitivity/Selectivity:

20 μV/35 dB

LW Tuner

Sensitivity:

50 μV
