12

beep sound (alarm) will output and the LCD will be displayed LOST TP TA, but the retune mode will not be
activated.

TA VOLUME

--- 18 will be displayed by default. Rotate the VOL knob to adjust the TA VOLUME value such as:

0<-->40.

REGIONAL

--- OFF will be displayed by default. Rotate the VOL knob to adjust the REGIONAL mode such as:

<-->OFF<-->ON<-->. If ON is selected when the AF search or PI seek, it will be implemented to station which have
all PI codes are the same as current station. If OFF is selected when AF search or PI seek, the regional code in the
format PI code is ignored, and a regional station will be possible received.

Radio mode

1. To select radio band
Press the BAND button shortly and repeatedly to select your desired radio band in sequence and circulation as
follows:
-->FM1-->FM2-->FM3-->MW1-->MW2--> .
2. To select the radio station manually or automatically
1) Under AUTO search mode, press >>| or |<< button hold for more than 1 seconds until MANUAL is displayed on
LCD to change into MANUAL search mode, then press >>| or |<< button shortly and repeatedly to manually search
up or down for the desired radio station for the current band.
2) Under MANUAL search mode, after 5 seconds without any operation, it will change into AUTO search mode
automatically. Then press >>| or |<< button shortly to manually search up or down for the strong signal radio station
for the current band.
3. To store the current station or turn on the preset station
1) Press one of the 6 number buttons hold for  more than 1 second until the second beep output to store the current
station in the preset memory bank of the number button for the current band. So the unit can store 30 preset stations.
When a RDS station is being stored, PI, PS, AF list are stored.
