AEG STEP 1200 XE - Инструкция по эксплуатации - Страница 12

22

23

......................... 730 W

......................... 370 W

................... 500-3000 min

-1

........................... 26 mm

......................... 45°

......................... 135 mm

......................... 100 mm

........................... 10 mm

........................... 20 mm

........................... 30 mm

........................... 10 mm

.......................... 2,4 kg

........................... 87 dB  (A)

........................... 98 dB  (A)

........................ 10,5 m/s

2

.......................... 1,5 m/s

2

........................ 11,5 m/s

2

.......................... 1,5 m/s

2

TECHNICAL DATA

Rated input ..............................................................................

Output ......................................................................................

Stroke rate under no–load .......................................................

Lengths of stroke .....................................................................

Bevel cuts up to .......................................................................

Cutting depth max. in:

  Soft- wood ............................................................................

 Hard-wood ............................................................................

 Steel .....................................................................................

  Non-ferrous metal .................................................................

 Aluminium .............................................................................

 Ceramics ..............................................................................

Weight according EPTA-Procedure 01/2003 ...........................

Noise/vibration information

Measured values determined according to EN 60 745.

Typically, the A-weighted noise levels of the tool are:

  Sound  power  level  (K = 3 dB(A)) ............................................

  Sound  pressure  level  (K = 3 dB(A)) .......................................

Wear ear protectors!

Total vibration values (vector sum in the three axes)

determined according to EN 60745.

Sawing of wood

  Vibration emission value a

h

...................................................

  Uncertainty K ........................................................................

Sawing of sheet metal

  Vibration emission value a

h

...................................................

  Uncertainty K ........................................................................

WARNING! Read all safety warnings and all

instructions, including those given in the accompanying

brochure.

 Failure to follow the warnings and instructions

may result in electric shock, fire and/or serious injury.

Save all warnings and instructions for future reference.

SAFETY INSTRUCTIONS

Wear ear protectors.

 Exposure to noise can cause hearing

loss.

Hold power tool by insulated gripping surfaces, when

performing an operation where the cutting accessory

may contact hidden wiring or its own cord.

Contact with

a „live“ wire will also make exposed metal parts of the power

tool „live“ and shock the operator.
Appliances used at many different locations including open

air should be connected via a residual current device of

30 mA or less.
Always wear goggles when using the machine. It is

recommended to wear gloves, sturdy non slipping shoes

and apron.
Sawdust and splinters must not be removed while the

machine is running.
Always disconnect the plug from the socket before carrying

out any work on the machine.
Only plug-in when machine is switched off.
Keep mains lead clear from working range of the machine.

Always lead the cable away behind you.
Always use the protective shields on the machine.

Do not use cracked or distorted saw blades.
Plunge cuts without pre–drilling a hole are possible with soft

materials (wood, light building materials for walls). Harder

materials (metals) must first be drilled with a hole

corresponding to the size of the saw blade.
The dust produced when using this tool may be harmful to

health. Do not inhale the dust. Wear a suitable dust

protection mask.

SPECIFIED CONDITIONS OF USE

This jig saw can cut wood, plastic and metal; it can cut

straight lines, bevels, curves, and internal cut–outs.
Do not use this product in any other way as stated for

normal use.

ENGLISH

WARNING

The vibration emission level given in this information sheet has been measured in accordance with a standardised test given

in EN 60745 and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for different

applications, with different accessories or poorly maintained, the vibration emission may differ. This may significantly increase

the exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or

when it is running but not actually doing the job. This may significantly reduce the exposure level over the total working period.

Identify additional safety measures to protect the operator from the effects of vibration such as: maintain the tool and the

accessories, keep the hands warm, organisation of work patterns.

ENGLISH

EC-DECLARATION OF CONFORMITY

We declare under our sole responsibility that this product is

in conformity with the following standards or standardized

documents.

EN 60745-1:2009 + A11:2010

EN 60745-2-11:2010

EN 55014-1:2006 + A1:2009 + A2:2011

EN 55014-2:1997 + A1:2001 + A2:2008

EN 61000-3-2:2006 + A1:2009 + A2:2009

EN 61000-3-3:2008

in accordance with the regulations

2011/65/EU (RoHs)

2006/42/EC

2004/108/EC

Winnenden, 2012-09-07

Rainer Kumpf

Director Product Development

Authorized to compile the technical file

MAINS CONNECTION

Connect only to single-phase a.c. current and only to the

system voltage indicated on the rating plate. It is also

possible to connect to sockets without an earthing contact

as the design conforms to safety class II.
Under the effect of extreme electromagnetic interferences

from the outside, temporary variations in the speed of

rotation could arise in particular cases.

MAINTENANCE

The ventilation slots of the machine must be kept clear at all

times.
Use only AEG accessories and spare parts. Should

components need to be exchanged which have not been

described, please contact one of our AEG service agents

(see our list of guarantee/service addresses).
If needed, an exploded view of the tool can be ordered.

Please state the ten-digit No. as well as the machine type

printed on the label and order the drawing at your local

service agents or directly at: AEG Electric Tools GmbH,

Max-Eyth-Straße 10, D-71364 Winnenden, Germany.

SYMBOLS

Please read the instructions

carefully before starting the

machine.

Always disconnect the plug from the socket

before carrying out any work on the

machine.

Accessory - Not included in standard

equipment, available as an accessory.

Do not dispose of electric tools together

with household waste material! In

observance of European Directive 2002/96/

EC on waste electrical and electronic

equipment and its implementation in

accordance with national law, electric tools

that have reached the end of their life must

be collected separately and returned to an

environmentally compatible recycling

facility.

Class II construction, tool in which

protection against electric shock does not

rely on basic insulation only, but in which

additional safety precautions, such as

double insulation or reinforced insulation,

are provided.
