background image

4

CAPABILITIES

ENGLISH

- Plug the machine into an easily accessible socket.
- To prevent electrical shock - do not use the appliance close to water, do not spill water on to the appliance, power cord or wall socket.

DO

 ensure the machine is on a stable surface.

DO

 test laminate scrap sheets and set the machine before final laminations.

DO

 remove staples and other metal articles prior to laminating.

DO

 keep the machine away from heat and water sources.

DO

 turn off the machine after each use.

DO

 unplug the machine when not in use for an extended period.

DO

 use pouches designed for use at the appropriate settings.

DO

 keep away from pets, while in use.

DO

 ensure self-adhesive pouches are only used with the cold setting.

DO NOT

 leave the power cord in contact with hot surfaces.

DO NOT

 leave power cord hanging from cupboards or shelves.

DO NOT

 use appliance if the power cord is damaged.

DO NOT

 attempt to open or otherwise repair the machine.

DO NOT

 exceed the machines quoted performance.

DO NOT

 allow children to use this machine without adult supervision.

DO NOT

 laminate sharp or metal objects (eg: staples, paper clips).

DO NOT

 laminate heat-sensitive documents (eg: tickets, ultrasounds etc) on hot

settings.

DO NOT

 laminate with self-adhesive pouches on hot settings.

DO NOT

 laminate an empty pouch.

IMPORTANT SAFETY INSTRUCTIONS - KEEP FOR FUTURE USE

LAMINATOR CONTROLS

A



On / off switch

B



Pouch selection buttons

 ( , 80, 125 microns)

C



Pouch / document entry slot

D



Pouch / document exit



Release lever (

 )

‘Auto Shut-Off’ function



If the machine is not active for 30 minutes, the ‘Sleep Mode’ function will

place the machine into standby mode. To operate the machine, press the

‘Power On’ button on the control panel.

‘Release’ function



To remove or re-align a pouch during lamination, activate the release lever

located at the rear of the machine. The pouch can only be removed from the

entry slot when the lever is activated.

t

For best results, use Fellowes

®

 brand pouches:

80 - 125 micron + cold pouches.

t

For self-adhesive (cold pouches) only use the cold setting.

t

This machine does not need a carrier to laminate. It is a carrier-free

mechanism.

t

Always put the item to be laminated into the appropriate sized pouch.

t

Always test laminate with a similar size and thickness before final process.

t

Prepare pouch and item for lamination. Place item within pouch centred and

touching the leading sealed edge. Ensure the pouch is not too large for the

item.

t

If required, trim excess material from around the item after lamination and

cooling.

t

When working with different pouch thickness’ (temperature settings) it is
recommended to first start with the thinnest pouches.

FEATURES & TIPS

Performance

Format A3/A4
Entry width

A3 = 318mm



A4 = 240mm

Pouch thickness (min)

80 microns

Pouch thickness (max)

125 microns

Warm up time (estimate)

3 minutes

Lamination speed (+/- 5%)

approx. 300 mm/min (fixed speed)

Number of rollers

2

Ready indication

Light

Release lever

Yes

Cold lamination

Yes

Technical Data

Voltage / Frequency / Current(Amps)  A3 = 220-240V AC, 50/60Hz, 3.4A



A4 = 220-240V AC, 50/60Hz, 3.4A

Wattage

A3 = 782 Watts



A4 = 782 Watts

Dimensions (HxWxD)

A3 = 75 x 435 x 110 mm



A4 = 75 x 342 x 110 mm

Net weight

A3 = 1.7 kg



A4 = 1.4 kg

Max document thickness

(laminating capacity)

0.4mm/0.02”

Maximum recommended usage: Moderate Use, 30 laminations per week. Heavier paper materials may have an effect on quoted usage.
