4
CAPABILITIES
ENGLISH
- The machine is for indoor use only. Plug the machine into an easily accessible socket.
- To prevent electrical shock - do not use the appliance close to water, do not spill water on to the appliance, power cord or wall socket.
DO
ensure the machine is on a stable surface.
DO
test laminate scrap sheets and set the machine before final laminations.
DO
remove staples and other metal articles prior to laminating.
DO
keep the machine away from heat and water sources.
DO
turn off the machine after each use.
DO
unplug the machine when not in use for an extended period.
DO
use pouches designed for use at the appropriate settings.
DO
keep away from pets, while in use.
DO NOT
leave the power cord in contact with hot surfaces.
DO NOT
leave power cord hanging from cupboards or shelves.
DO NOT
use appliance if the power cord is damaged.
DO NOT
attempt to open or otherwise repair the machine.
DO NOT
exceed the machines quoted performance.
DO NOT
allow children to use this machine without adult supervision.
DO NOT
laminate sharp or metal objects (eg: staples, paper clips).
DO NOT
laminate heat-sensitive documents (eg: tickets, ultrasounds etc) on hot
settings.
DO NOT
laminate with self-adhesive pouches on hot settings.
DO NOT
laminate an empty pouch.
IMPORTANT SAFETY INSTRUCTIONS - KEEP FOR FUTURE USE
LAMINATOR CONTROLS
A
On / off 80mic/125mic switch
B
Ready LED
C
Release lever (
)
D
Carry handle
E
Pouch / document entry slot
F
Pouch / document exit
G
Power on LED
‘Release’ function
To remove or re-align a pouch during lamination, activate the release lever
located on the top of the machine. The pouch can only be removed from the
entry slot when the lever is activated.
t
For best results, use Fellowes ® brand pouches: Enhance 80, Capture 125
t
This machine does not need a carrier to laminate. It is a carrier-free
mechanism.
t
Always put the item to be laminated into the appropriate sized pouch.
t
Always test laminate with a similar size and thickness before final process.
t
Prepare pouch and item for lamination. Place item within pouch centred and
touching the leading sealed edge. Ensure the pouch is not too large for the
item.
t
If required, trim excess material from around the item after lamination and
cooling.
FEATURES & TIPS
Performance
Format
A3 or A4
Entry width
A3 = 325mm
A4 = 240mm
Pouch thickness (min)
80 microns (per side)
Pouch thickness (max)
125 microns (per side)
Warm up time (estimate)
4 minutes
Cool down time
60-90 minutes
Lamination speed (+/- 5%)
approx. 30cm/min (fixed speed)
Number of rollers
2
Ready indication
Light
Release lever
Yes
Clear Path / Anti-jam engine
Yes
Technical Data
Voltage / Frequency / Current(Amps)
A3 = 220-240V AC, 50/60Hz, 2.0A
A4 = 220-240V AC, 50/60Hz, 1.5A
Wattage
A3 = 460 Watts
A4 = 300 Watts
Dimensions (HxWxD)
A3 = 495 x 160 x 105 mm
A4 = 400 x 160 x 105 mm
Net weight
A3 = 1,5 kg
A4 = 1.2 kg
Max document thickness
(laminating capacity)
0.5mm/0.02”
