instrUction MAnUAl
instrUction

please read this instruction carefully in order to

use the scale correctly & keep the scale in good

condition.

FEAtUrEs

1.   indicate volume of water and milk

2.    two weight unit systems g/lb:oz  convertible

3.    Two volume unit systems ml/fl’oz convertible

4.   low battery power/overload indication

5.   With high precision strain gauge sensor

6.   With tare function

7.   auto off

BAttErY

1 pc lithium battery (cr2032)

please remove the isolation

sheet from battery contact

before use. please observe the

polarity.

to rEPlAcE BAttErY

1.  open battery case cover on

the back of scale.

2.  Bend the small black tab

outwards and the battery will

come out. take note not to

bend the contact.

3.    install new battery by putting one side

of battery beneath the contact and then

pressing down the other side.

lcD

working MoDEs

Unit convErsion BUtton

at the bottom of scale, you can

find a unit conversion button as

shown in picture.

to convErt wEight Unit

if the scale is with both unit systems of Metric (g,

ml) or Imperial (lb:oz, fl’oz), press MODE button

to choose working mode (weight, milk volume,

water volume), then press   unit conversion

button to convert between two systems. take

the conversion of weight unit for example: (see

fig. 1)
*    When setting g as weight unit, the default

volume unit is ml;

*    When setting lb: oz as weight unit, the default

volume unit is fl’oz.

remark: the unit system of scale depends

on sales destination or the requirement of

distributor.

to stArt wEighing

1.   Weighing mode (see fig. 2)

A.   Place the scale on a solid and flat surface.

B.   place bowl (if used) on the scale before

turning on the scale.

C.   Press „ON/OFF“ to enter weighing mode.

d.   Wait until lcd shows all information.

E.   load weighing object on to start weighing,

lcd wil l show the weight reading.

F.   if the weighing object is water or milk, press

ModE button to choose volume mode and

view the volume of weighing object.

2.   volume indication mode

(see fig. 3)

A.  Place the scale on a solid and flat surface.

B.  Press“ON/OFF“ to turn on the scale.

C.  Wait until LCD shows „0“, and press MODE

button to choose „Water“ or „Milk“ mode.

d.  put a liquid container onto the scale platform.

E.  Press ZERO button to reset LCD to „0“.

F.   pour liquid (water or milk) into the container,

lcd shows the volume of the liquid.

G.  Press MODE button to choose „Weight“

mode and view the weight of liquid.

„ZERO“ OR „TARE“ FUNCTION

to weigh different loads consecutively without

removing loads from the scale. Put first Load

on the scale, get weight reading. press ZEro

button to reset the LCD reading to „0“ before

adding next load. You can repeat this operation.

Condition 1: “ZERO” function

(see fig. 4)

When total sum of all loads on scale ≤ 4% of

scale´s max. weight capacity. (4% = 80g when

capacity is 2kg; 200g when capacity is 5kg)

LCD will show „0“ each time ZERO is pressed.

Icon „0“ will show on lower left corner of LCD,

indicating „ZERO“ function is active. Max. weight

capacity remains unchanged.

Condition 2: “TARA” function

(see fig. 5)

When total sum of all loads on scale > 4% of

scale´s max. weight capacity. (4% = 80g when

capacity is 2kg; 200g when capacity is 5kg)

LCD will show „0“ each time ZERO is pressed.

Icon „T“ will show on upper left corner of LCD,

indicating „TARE“ function is active. Max. weight

capacity is reduced by total weight of all loads.

Under this condition:

By pressing ZEro, you can see the total weight

of all loads on the scale. if you want to weigh

more loads, just press ZEro to reset lcd

reading to ‚0‘ again.

AUto shUt oFF

auto shut-off occurs if display

shows ‚0‘ or shows the same

weight reading for 2 minutes.

MAnUAl shUt oFF

to maximize battery life, always

press on/oFF again to turn off

the scale after using.
Note: when display shows „0“,

press „ON/OFF“ to turn off the

scale; when display shows weight reading, press

„ON/OFF“ for 3 seconds to turn off the scale.

wArning inDicAtors

1.  replace new battery.

2.  scale overload. remove

item to avoid damage. Max.

weight capacity is indicated

on the scale.

clEAning AnD cArE

1.   clean the scale with a slightly damp cloth.

do not immerse the scale in water or use

chemical/abrasive cleaning agents.

2.   all plastic parts should be cleaned

immediately after contact with fats, spices,

vinegar and strongly flavored/colored foods.

avoid contact with acids citrus juices.

3.   Always use the scale on a hard, flat surface.

do not use on carpet.

Environment friendly disposal

You can help protect the environment! please

remember to respect the local regulations: hand

in the non-working electrical equipments to an

appropriate waste disposal center.
