www.timberk.com • Electric air conditioner

8

AUTO mode – SMART (FEEL)

In auto mode, depending on the air temperature in the room, the conditioner

selects needed temperature parameters by itself in the following order:

7. OPERATING MODES

Temperature indoors

Automatic mode sele ction

Automatically maintained temperature

if <20° С

then HEAT mode shall be turned on

23° С

if <20° С - 26° С

then DRY mode shall be turned on

18° С

if <26° С

then COOL mode shall be turned on

23° С

In the Smart mode it is possible to change the threshold of mode transition.

When the Smart mode is on, the display indicates «-». Press the Temp

+/- buttons, and «-» will change to +1. ..+2 or -1 ...-2. Shift range of this

threshold is within -2...+2 ° from temperatures by default.

COOL, HEAT

and

FAN

1. Turn the conditioner on by pressing the ON/OFF button.
2. Press the MODE button to select COOL, HEAT or FAN mode manually.
3. Press the TEMP (up-down) buttons to set the desired air temperature in

the room (except for the FAN mode).
4. Press the FAN SPEED button on the remote control to select the fan

rotation speed: AUTO, LOW, MIDDLE, HIGH, and the conditioner will start

working in accordance with the selected setting.
5. To turn the conditioner off, press the ON/OFF button again. In FAN mode

air temperature in the room shall not be set.

DRY

Turn the conditioner on by pressing the ON/OFF button. Press the MODE

button to select the DRY mode. The conditioner will start working in the set

mode. To turn the conditioner off, press the ON/OFF button again.

SUPER (TURBO) operating mode

When you press the SUPER button on the remote control, the conditioner

starts working in heavy-duty mode for maximum cooling (in cooling mode)

or for maximum heating (in heating mode).

TIMER mode

The procedure for timer setup:
If the conditioner is off, then press the TIMER button to activate the

automatic turning on. Press this button again to set the turn-on time in

the set time interval. To cancel the timer mode, press the TIMER button

once more

SLEEP (Night Care) button.

Button «SLEEP» (Night Care). Using this button, you may turn the sleep

mode on and off. In this mode, if working for cooling, the conditioner will

increase temperature by 1 °С from the specified one within two hours.

If working for heating, the conditioner will decrease temperature by 1 °С

from the specified one within two hours. After 10 hours of operation the

conditioner will turn off automatically.

Remote control.
Work with remote control.

Installation and replacement of batteries: install two LR03 alkaline batteries,

according to the polarity shown on the remote control.
In order to avoid malfunction of the remote control, do not insert used or

various-type batteries in it.
If the conditioner is not used for a long time, remove batteries from the

remote control. Otherwise, battery solution may leak and damage the

panel.
In case of normal operation of the conditioner, the average service life of

batteries is 6 months.
Replace the batteries, if command receiving is not confirmed by an audio

signal or if the display does not indicate a command transfer sign.
When generating commands from the remote control, point an infrared

radiator to the signal receiver on the internal unit. Hold the remote control

at the distance of no more than 8 m from the internal unit.
The remote control will not work, if there are curtains, doors or other

objects between it and the internal unit. Prevent contact of the remote

control with water and do not expose it to direct sunlight and heat sources.
