www.timberk.com • Electric air conditioner

www.timberk.com • Electric air conditioner

14

15

NOTE:

1.In the low temperature heating mode, the fan speed
was default to Auto and nonajusatable.
2.In the low temperature heating mode, «TURBO» and
«QUIET» can’t be set. If enter the low temperature
heating mode,the turbo and quiet function that started
before will be canceled. As well as when exit the low
temperature heating mode, it will not resume.
3.When exit from the low temperature heating mode,
the speed and temperature will turn into the original
condition before it started.
4.You can set up other function.

8. MAINTENANCE

• Before cleaning unplug the conditioner.
• Cleaning of the indoor unit and remote control board:
• Indoor unit and remote control board should be cleaned with a dry soft cloth.
• If the indoor unit is too unclean, moisten the cloth with cold water.
• It is prohibited to clean the remote control board with moist cloth.
• In order to avoid the damage of paint or details of the conditioner, do not

clean it with brushes and do not leave them on the surface of indoor unit.

• In order to avoid the damage of surface or deformation of the conditioner

details, do not clean it with petrol, solvents, cleaning powders or other

chemically active substances.

• Before a sustained interruption in the conditioner work:
• Turn the conditioner on for several hours in the FAN mode. It will allow you to

dry its inner cavities

• Unplug the conditioner. Remove the batteries from the remote control board.
• Checks before starting:
• Make sure that an air filter is installed.
• Make sure that air inlet and outlet grilles of the outdoor unit are not blocked

by foreign objects.

• Cleaning of air filter
• Air filter cleans the air entering the conditioner from dust and foreign

particles. If the filter is contaminated, the conditioner capacity decreases

sharply.

• If the conditioner is operated permanently, the filter should be cleaned once

per two weeks.

• If the conditioner is installed in a room with dusty atmosphere, then the air

filter should be cleaned more often.

• To remove the filter, open the indoor unit panel.
• Remove air filters. Clean the filter with a vacuum cleaner or rinse it in clean

water. If the filter is contaminated heavily, clean it with a soft brush and wash in

diluted washing solution, then dry it in a cool place.

• While cleaning the filter with the vacuum cleaner, hold it with contaminated

surface up. While washing the filter in water, hold it with contaminated surface

down.

• Do not dry the filter in the sun or near a fire.
• Set the air filter to initial position and close the panel.

9. TROUBLESHOOTING

11.SERVICE LIFE

In case of emergency, please, use the troubleshooting methods shown in

tables. If it is impossible to solve problems with these methods, apply to

the service center.
Failures and their possible reasons:

12. UTILIZATION RULES

10. TRANSPORTATIOM AND STORAGE

We are exploring new technologies and we constantly improving the quality

of our products. That’s why specifications, design and accessories are

subject to change without any specific notice.

Service life of the appliance is 10 years provided that the respective

installation and operation rules are observed.

Date of the conditioner manufacture is shown in a serial number of the

device. For more details, please, ask a shop assistant.

* This product must have storage in dry, well-ventilated space of warehouse

at the temperature not lower than -30°C.

Temperature

requirements*
Humidity

requirements*

Transportation and

storage

From -30° to +50°

From 15% to 85%

(without a condensate)

Upon expiration of the service life, the appliance should be utilized in

accordance with norms, regulations and procedures effective in the place

of utilization.

Failure

Possible reason

Actions

The conditioner does

not work

Interruptions in power supply

Wait for restoration of power
supply

Batteries in the remote control
board are low

Replace the batteries

Time of tuming on is set by
the timer

Wait till the conditooner turns
on by the timer or cancel the
timer setting

Insufficient cooling or

heating capacity

The set air temperature is too
high or too low

Set the air temperature
correctly

The air filter is clogged with dust

Clean the air filter

Foreign objects block the air intel
and retum air grillages of the
outdoor unit

Remove foreign objects

The conditioner works,

but does not cool or

heat the room

A three-minute delay of
compressor tuming on

Wait a little

The air temperature is set
incorrectly

Set the temperature correctly
