En-7

● OPERATING INSTRUCTIONS ●

Even if these items are checked, when the unit does not recover from the

trouble, stop using the air conditioner and consult your dealer.

Symptom

Explanation & Check points

Indoor Unit

The unit cannot be operated.

•  Is the breaker turned on?

•  Is the power supply plug connected?

•  Is the ON timer set?

 Page 5

The horizontal vane does not

move.

•  Are  the  horizontal  vane  and  the  vertical  vane

installed correctly?

•  Is the fan guard deformed?

•  When  the  breaker  is  turned  on,  the  horizontal

vanes’ position will be reset in about a minute.

After the reset has completed, the normal hori-

zontal vanes’ operation resumes. The same is

true in the emergency cooling operation.

The unit cannot be operated for

about 3 minutes when restarted.

•  This protects the unit according to instructions

from the microprocessor. Please wait.

Mist is discharged from the air

outlet of the indoor unit.

•  The cool air from the unit rapidly cools moisture

in the air inside the room, and it turns into mist.

The swing operation of the HORI-

ZONTAL VANE is suspended for a

while, then restarted.

•  This is for the swing operation of the HORIZON-

TAL VANE to be performed normally.

The airfl ow direction changes

during operation.

The direction of the horizontal

vane cannot be adjusted with

the remote controller.

•  When  the  unit  is  operated  in  COOL  or  DRY

mode, if the operation continues with air blow-

ing down for 0.5 to 1 hour, the direction of the

airfl ow  is  automatically  set  to  upward  position

to prevent water from condensing and dripping.

•  In  the  heating  operation,  if  the  airfl ow  tem-

perature is too low or when defrosting is being

done,  the  horizontal  vane  is  automatically  set

to horizontal position.

The operation stops for about

10 minutes in the heating

operation.

•  Outdoor unit is in defrost.

  Since  this  is  completed  in  max.10  minutes,

please wait. (When the outside temperature is too

low and humidity is too high, frost is formed.)

The unit starts operation by

itself when the main power is

turned on, but hasn’t received

signal from the remote control-

ler.

•  These  models  are  equipped  with  an  auto

restart  function.  When  the  main  power  is

turned  off  without  stopping  the  unit  with  the

remote  controller  and  is  turned  on  again,  the

unit starts operation automatically in the same

mode  as  the  one  set  with  the  remote  control-

ler  just  before  the  shutoff  of  the  main  power.

Refer to “Auto restart function”.

 Page 4

In COOL/DRY mode, when the

room temperature reaches near

the set temperature, the outdoor

unit stops, then the indoor unit

operates at low speed.

•  When the room temperature deviates from the

set  temperature,  the  indoor  fan  starts  running

according to the settings on the remote control-

ler.

The indoor unit discolors over

time.

•  Although plastic turns yellow due to the infl uence

of  some  factors  such  as  ultraviolet  light  and

temperature, this has no effect on the product

functions.

Outdoor Unit

The fan of the outdoor unit does

not rotate even though the com-

pressor is running. Even if the

fan starts to rotate, it stops soon.

•  When  the  outside  temperature  is  low  during

cooling operation, the fan operates intermittently

to maintain suffi cient cooling capacity.

Water leaks from the outdoor

unit.

•  During COOL and DRY operations, pipe or pipe

connecting sections are cooled and this causes

water to condense.

•  In  the  heating  operation,  water  condensed  on

the heat exchanger drips down.

•  In the heating operation, the defrosting operation

makes ice forming on the outdoor unit melt and

drip down.

White smoke is discharged from

the outdoor unit.

•  In the heating operation, vapor generated by the

defrosting operation looks like white smoke.

Remote controller

The display on the remote

controller does not appear or it

is dim. The indoor unit does not

respond to the remote control

signal.

•  Are the batteries exhausted?

 Page 3

•  Is  the  polarity  (+,  -)  of  the  batteries  correct?

 Page 3

•  Are any buttons on the remote controller of other

electric appliances being pressed?

Symptom

Explanation & Check points

Does not cool or heat

The room cannot be cooled or

heated suffi ciently.

•  I s   t h e   t e m p e r a t u r e   s e t t i n g   a p p r o p r i a t e ?

 Page 4

•  Is  the  fan  setting  appropriate?  Please  change

fan speed to High or Super High.

 Page 4

•  Are the fi lters clean?

 Page 6

•  Is  the  fan  or  heat  exchanger  of  the  indoor  unit

clean?

•  Are there any obstacles blocking the air inlet or

outlet of the indoor or outdoor unit?

•  Is a window or door open?

•  It  may  take  a  certain  time  to  reach  the  setting

temperature or may not reach that depending on

the size of the room, the ambient temperature,

and the like.

The room cannot be cooled

suffi ciently.

•  When a ventilation fan or a gas cooker is used

in a room, the cooling load increases, resulting

in an insuffi cient cooling effect.

•  When the outside temperature is high, the cooling

effect may not be suffi cient.

The room cannot be heated

suffi ciently.

•  When the outside temperature is low, the heating

effect may not be suffi cient.

Air does not blow out soon in

the heating operation.

•  Please wait as the unit is preparing to blow out

warm air.

Airfl ow

The air from the indoor unit

smells strange.

•  Are the fi lters clean?

 Page 6

•  Is  the  fan  or  heat  exchanger  of  the  indoor  unit

clean?

•  The  unit  may  suck  in  an  odor  adhering  to  the

wall, carpet, furniture, cloth, etc. and blow it out

with the air.

Sound

Cracking sound is heard.

•  This sound is generated by the expansion/con-

traction of the front panel, etc. due to change in

temperature.

“Burbling” sound is heard.

•  This  sound  is  heard  when  the  outside  air  is

absorbed from the drain hose by turning on the

range hood or the ventilation fan, making water

fl owing in the drain hose to spout out.

  This  sound  is  also  heard  when  the  outside  air

blows  into  the  drain  hose  in  case  the  outside

wind is strong.

Mechanical sound is heard

from the indoor unit.

•  This is the switching sound in turning on/off the

fan or the compressor.

The sound of water fl owing is

heard.

•  This  is  the  sound  of  refrigerant  or  condensed

water fl owing in the unit.

Hissing sound is sometimes

heard.

•  This  is  the  sound  when  the  fl ow  of  refrigerant

inside the unit is changed.

In the following cases, stop using the air conditioner and consult your

dealer.

•  When water leaks or drips from the indoor unit.

•  When the upper operation indicator lamp blinks.

•  When the breaker trips frequently.

•  The remote control signal is not received in a room where an electronic ON/OFF

type fl uorescent lamp (inverter-type fl uorescent lamp, etc.) is used.

•  Operation of the air conditioner interferes with radio or TV reception. An ampli-

fi er may be required for the affected device.

•  When an abnormal sound is heard.

•  When any refrigerant leakage is found.

W

HEN  YOU  THINK  THAT  TROUBLE  HAS  OCCURRED
