Hyundai Electronics H-PAC-09C1UR8 - Инструкция по эксплуатации - Страница 8

8.

EN

Electric air conditioner

portable type

Note:

1. Hold the drain plug cover, and the water properly.
2. During drainage, the housing may be tilted slightly backwards.
3. When the water is drained, stick water plug and tighten the drain cap.

ATTENTION!

Disconnect the unit from the mains prior to cleaning.

1. When cleaning the air conditioner, do not use gasoline, solvents and other chemically active

substances.

2. To avoid electric shock and damage to electrical components, do not pour water on the air

conditioner

from a tap or a hose.

3. Do not use the air conditioner if the power cord is damaged. On the subject of replacing a

damaged power cord, contact an authorized service center. Air filter clogging with dust particles

impairs the air conditioner operation efficiency, therefore clean the filter no less than once in two

weeks. Filter removal/installation Remove the air filter in the direction, indicated by the arrow.

Slightly push it and then take it out from the device for cleaning.

Installation of the filter is performed in the reverse order. Filter cleaning At first, carefully clean

the filters by means of vacuum cleaners. Then immerse the filter in warm water (about 40°C) with

a soft detergent, wash it and dry it without exposure to direct sunlight.

Air intakes (heat exchangers)

Use a vacuum cleaner for cleaning. Case Wipe the surface by a damp cloth and dry it by a soft dry

cloth.

Automatic condensate removal Condensate is automatically removed from the unit. Moisture

inside the

unit starts to evaporate and is removed from the unit through an air duct (or an air diffuser) in the

form of steam.

Fig. 12

7. MAINTENANCE
