9.

Electric  air conditioner (split system)

EN

Cooling/Heating operation mode

Press the “MODE” button, select the Cooling or Heating operation mode.
2. By pressing the “         ”or “         ” button, you can set the temperature range from 16℃
(60℉)~32℃(90℉), the display changes as you touch the button.
3. By pressing the “SPEED” button, you can select the fan speed from LOW, MID, HIGH, AUTO.
4. Press the “ON/OFF” button, the air-conditioner starts to operate.
5. Press the “ON/OFF” button again, the air-conditioner stops.

Note: The cold wind type has no heating function.

Fan operation mode

1. Press the “MODE” button, select the fan operation mode.
2. By pressing the “SPEED” button, you can select the fan speed from LOW, MID, HIGH.
3. Press the “ON/OFF” button, the air-conditioner starts to operate.
4. Press the “ON/OFF” button again, the air-conditioner stops.

Note: In the fan operation mode, the temperature settings is non-effective.

Drying operation mode

Press the “MODE” button, select the drying operation mode.
2. By pressing the “          ”or “           ” button, you can set the temperature range from 16℃
(60℉)~32℃(90℉), the display changes as you touch the button.
3. By pressing the “SPEED” button, you can select the fan speed from LOW, MID, HIGH, AUTO.
4. Press the “ON/OFF” button, the air-conditioner starts to operate.
5. Press the “ON/OFF” button again, the air-conditioner stops.

Backlight function (for remote controllers with such function only)

The remote controller has a backlight which can be turned on by pressing any button for the
convenience of operation in darkness. The backlight will be automatically turned off if there
is no operation within 10 seconds.

8. MAINTENANCE

•  Before cleaning unplug the conditioner.

•  Cleaning of the indoor unit and remote control board:

•  Indoor unit and remote control board should be cleaned with a dry soft cloth.

•  If the indoor unit is too unclean, moisten the cloth with cold water.

•  It  is prohibited to clean the remote control board with moist cloth.

•  In order to avoid the damage of paint or details of the conditioner, do not clean it with brush-

es and do not leave them on the surface of indoor unit.

•  In order to avoid the damage of surface or deformation of the conditioner details, do not

clean it with petrol, solvents, cleaning powders or other chemically active substances.

•  Before a sustained interruption in the conditioner work:

•  Turn the conditioner on for several hours in the FAN mode. It will allow you to dry its inner

•  cavities

•  Unplug the conditioner. Remove the batteries from the remote control board. Checks before

starting:

•  Make sure that an air filter is installed.

•  Make sure that air inlet and outlet grilles of the outdoor unit are not blocked by foreign

objects.

•  Cleaning of air filter

•  Air filter cleans the air entering the conditioner from dust and foreign particles. If the filter is

contaminated, the conditioner capacity decreases sharply.

•  If the conditioner is operated permanently, the filter should be cleaned once per two weeks.

•  If the conditioner is installed in a room with dusty atmosphere, then the air filter should be

cleaned more often.

•  To remove the filter, open the indoor unit panel.

•  Remove air filters. Clean the filter with a vacuum cleaner or rinse it in clean water. If the filter

is contaminated heavily, clean it with a soft brush and wash in diluted washing solution, then

dry it in a cool place.

•  While cleaning the filter with the vacuum cleaner, hold it with contaminated surface up. While

washing the filter in water, hold it with contaminated surface down.

•  Do not dry the filter in the sun or near a fire.

•  Set the air filter to initial position and close the panel.

SET

ON/OFF

FEAN

HIGH

MID

LOW

AUTO
COOL
DRY
HEAT

SET TEMPERATURE (°C)

MODE

TURBO

DISPLAY

iFEEL

HEALTH

iCLEAN

ECO

ELE.H

ANTI-F

°C/°F

SPEED

SLEEP

SWING

SWING

TIMER

SET

ON/OFF

FEAN

HIGH

MID

LOW

AUTO
COOL
DRY
HEAT

SET TEMPERATURE (°C)

MODE

TURBO

DISPLAY

iFEEL

HEALTH

iCLEAN

ECO

ELE.H

ANTI-F

°C/°F

SPEED

SLEEP

SWING

SWING

TIMER

SET

ON/OFF

FEAN

HIGH

MID

LOW

AUTO
COOL
DRY
HEAT

SET TEMPERATURE (°C)

MODE

TURBO

DISPLAY

iFEEL

HEALTH

iCLEAN

ECO

ELE.H

ANTI-F

°C/°F

SPEED

SLEEP

SWING

SWING

TIMER

SET

ON/OFF

FEAN

HIGH

MID

LOW

AUTO
COOL
DRY
HEAT

SET TEMPERATURE (°C)

MODE

TURBO

DISPLAY

iFEEL

HEALTH

iCLEAN

ECO

ELE.H

ANTI-F

°C/°F

SPEED

SLEEP

SWING

SWING

TIMER
